Key Features

• Type B — Double-Ended (ballast bypass; line voltage to both ends)
• High efficacy ~150 lm/W (1650 lm at 11W)
• 4000K neutral/cool white; 80 CRI
• 50,000 hr operating life; 5-year limited warranty
• Rated for damp locations; cULus safety

Product Specifications

• Model Number: 93117214G
• Ordering Code: LED11BDT8/G4/840
• Type: UL Type B, double-ended glass T8
• Wattage: 11W (120–277V)
• Lumens / Efficacy: ~1650 lm / ~150 lm/W
• CCT / CRI: 4000K / 80 CRI
• Dimming: Non-dimmable
• Base / Size: G13 bi-pin, T8 (Ø1"), MOL 48"
• Environment: Damp location rated; −20°C to +45°C operating
• Certifications: cULus; DLC (check QPL); RoHS
• Warranty: 5-year limited
• Pack / UPC: Std pack 20; UPC 043168509725

Applications

• Offices, retail, warehouses, parking garages
• Garages, basements, utility rooms (damp-rated)

Ballast-bypass (UL Type B), double-ended wiring LED T8 designed to retrofit 4ft T8 fixtures. Operates on 120–277V line voltage, delivers ~1650 lm at 80 CRI, and is non-dimmable. Rated 50,000 hours with a 5-year limited warranty.

Installation Note (Safety): This is a Type B double-ended tube. Bypass/remove the ballast, supply line voltage to the lamp holders as per wiring diagram, and follow all local codes. Installation by a qualified electrician is recommended.
