Product Overview
GE 23423 21A/R40/FL 250W 12V Low Voltage Frosted R40 Reflector Flood Lamp - Brass E26 Base
High-output 250-watt low voltage incandescent reflector flood lamp designed for swimming pool, spa, and wet location applications. Features frosted R40 bulb with brass E26 medium base, delivering 2850 lumens of 3000K warm white light. Heat-resistant glass construction with 1000-hour rated life.
Technical Specifications
Order Code:23423
Description:21A/R40/FL
Wattage:250W
Voltage:12V (Low Voltage)
Bulb Type:R40 Reflector Flood
Bulb Finish:Frosted
Base Type:Brass E26 Medium Screw Base
Filament:C-2V
Initial Lumens:2850
Center Beam Candlepower (CBCP):1600
Max Beam Candlepower (MBCP):2400
Efficacy:11.4 lumens per watt
Color Temperature:3000K Warm White
Maximum Overall Length (MOL):6.69 inches (169.7 mm)
Bulb Diameter:5.0 inches (127.0 mm)
Rated Average Life:1000 hours
Burn Position:Horizontal ±15° or Base Down
Bulb Material:Heat Resistant Glass
Package Quantity:24 per case
UPC:043168234238
Manufacturer:GE Lighting (General Electric)
Primary Applications
- Swimming pool lighting (wet locations)
- Spa and hot tub illumination
- Outdoor flood lighting
- Recessed downlighting
- Accent and display lighting
- General area illumination requiring 12V operation
Key Features & Benefits
- Low Voltage Operation: 12V design for safe wet location use
- Durable Construction: Heat-resistant glass with brass base for corrosion resistance
- Frosted Finish: Diffused light output reduces glare
- High Output: 2850 lumens with concentrated beam pattern
- Reliable Performance: 1000-hour rated life in proper operating position
- Wet Location Rated: Suitable for swimming pools and spa applications
Important Safety Information
WARNING: Pressurized Lamp
Unexpected lamp rupture may cause injury, fire, or property damage. Use only in enclosed fixtures rated for this product.
CAUTIONS:
- Do not exceed rated voltage (12V only)
- Avoid direct water, liquid, or metal contact during operation
- Do not use if outer glass is scratched or broken
- Base temperature must not exceed 500°F (260°C)
- Use only in fixtures rated for this specific lamp
- Operate only in specified position: Horizontal ±15° or Base Down
- Turn power off before installation or removal
- Allow lamp to cool before handling
Operating Requirements
- Requires 12V low voltage transformer or power supply
- Not for use on 120V household circuits
- Use only in enclosed fixtures rated for R40 reflector lamps
- Fixture must be rated for wet locations when used outdoors
- Do not use with dimmers unless specifically rated for low voltage operation
Compatible Replacements
Direct replacement for 250W 12V R40 reflector flood lamps with E26 medium base. Cross-reference: 21A/R40/FL-12V, R40 250W 12V Flood.
