Product Overview
Ushio 1000060 BLC 30W 120V S11 Incandescent Projection Lamp - BA15d Base
Professional 30-watt incandescent projection lamp featuring S11 bulb shape and BA15d double contact bayonet base. Delivers 400 lumens with 2775K color temperature and CC-2V filament design. Designed for audio/visual equipment, stage lighting, film projectors, and theater fixtures. 50-hour rated life with base down/horizontal burn position.
Technical Specifications
Key Features
- S11 Bulb Shape: Compact sign-style bulb for projector and optical applications
- BA15d Base: Double contact bayonet for secure, vibration-resistant mounting
- CC-2V Filament: Precision filament design for consistent output
- Clear Finish: Maximum light transmission for projection applications
- Base Down/Horizontal Operation: Optimized for projector and stage fixtures
- 50-Hour Life: Standard life rating for projection lamps
- Made in Japan: Manufactured under strict quality standards
Primary Applications
- Audio/visual equipment and projectors
- Stage and theater lighting fixtures
- Film projectors (8mm, 16mm, 35mm)
- Slide projectors
- Optical instruments
- Microscope illumination
- Sign and indicator lighting
Important Usage Information
Short Life Rating
This lamp has a 50-hour rated life, which is standard for incandescent projection lamps. This short life is due to the high filament temperature required for optimal color temperature and light output in projection applications. For applications requiring longer life, consider LED or halogen alternatives.
Cross Reference Numbers
Equivalent to: BLC, INC120V-30W, 30W 120V S11 BA15d
Similar Products: BLC/120V/30W (generic), other S11 projection lamps
Technical Information
- 120V line voltage operation - no transformer required
- BA15d base (bayonet twist-lock) - not compatible with BA15s or other bases
- 50-hour rated life typical for projection lamps
- Base down/horizontal burn position required for optimal performance and life
- CC-2V filament design for stable output
- Clear S11 bulb for maximum light transmission
Safety Information
Important Safety Notes
- Only for use in approved fixtures
- Operate only in base down or horizontal position
- Use gloves when handling to prevent oil contamination on bulb surface
- Allow lamp to cool before replacement
- Ensure proper ventilation in enclosed fixtures
- Contains mercury - dispose according to local regulations
