GE 72269 GE132MAX-G-N Electronic Ballast – 120-277V | Instant Start | Normal Ballast Factor | UltraMax® General Series | For (1) F32T8 and Compatible T8 Lamps

Reliable multi-volt instant start electronic ballast with 0.87 normal ballast factor, anti-striation control, and cold-weather starting – designed for general fluorescent lighting applications using one compatible T8 lamp.

Quick Specs

• Brand: GE Lighting
• Series: UltraMax® General Series
• Model: GE132MAX-G-N
• Replaces: GE-132-MV-N
• Product Code: 72269
• Ballast Type: Electronic Fluorescent Ballast
• Starting Method: Instant Start
• Input Voltage: 120-277V
• Lamp Compatibility: (1) F32T8 plus compatible 24in, 36in, and 48in T8 lamp families commonly listed for this ballast series
• Ballast Factor: 0.87 (Normal)
• Efficiency: >90%
• Minimum Starting Temperature: -20°F
• Maximum Case Temperature: 70°C
• THD: <10%
• Sound Rating: A (20-24 decibels)
• Housing Dimensions (L x W x H): 9.5 in x 1.3 in x 1.18 in
• Compliance: FCC 47 CFR Part 18 Non-Consumer, RoHS, UL Type 1 Outdoor, UL Type CC
• Additional Features: Active Current Regulation, Anti-Striation Control

Product Overview

The GE 72269 GE132MAX-G-N is a multi-volt instant start electronic ballast designed for general fluorescent lighting applications. It is commonly positioned as a 1-lamp F32T8 ballast in the GE UltraMax® General Series, operating across 120-277V systems with a 0.87 normal ballast factor. :contentReference[oaicite:5]{index=5}

This ballast combines high efficiency, anti-striation control, and cold-temperature starting in a lightweight low-profile housing. It is a solid fit for commercial fluorescent fixtures where standard-output T8 performance and broad voltage flexibility are required. :contentReference[oaicite:6]{index=6}

Why Choose This Product

• Multi-volt flexibility: Operates on 120V through 277V systems.
• Normal ballast factor: Good match for standard-output T8 lighting applications.
• Cold-weather starting: Rated to start down to -20°F.
• Anti-striation control: Helps improve light quality.
• Active current regulation: Supports stable lamp output.
• Compact housing: Low-profile design fits many fixture channels.

Technical Specifications

Dimensions

Applications

• Commercial fluorescent strip fixtures
• Office and institutional lighting
• Maintenance replacements for 1-lamp T8 systems
• General fluorescent retrofit applications
• Fixtures requiring multi-volt T8 ballast compatibility

Compatibility & Replacement

Fixture type: Designed primarily for 1-lamp F32T8 applications, with older GE family listings also associating it with compatible 24-inch, 36-inch, and 48-inch T8 lamp families. :contentReference[oaicite:7]{index=7}

Replacement note: Product code 72269 is commonly listed as GE132MAX-G-N, replacing the older GE-132-MV-N designation. :contentReference[oaicite:8]{index=8}

Before ordering, confirm:

• Lamp type: Verify your exact lamp family and wattage.
• Lamp count: Confirm the fixture uses one lamp.
• Input voltage: Confirm supply is between 120V and 277V.
• Physical size: Verify ballast channel fit.
• Replacement goal: Match normal ballast factor performance if replacing like-for-like.

Ordering Information

• Brand: GE Lighting
• Series: UltraMax® General Series
• Model: GE132MAX-G-N
• Replaces: GE-132-MV-N
• Product Code: 72269
• Description: Multi-volt instant start electronic ballast for one compatible T8 lamp with normal ballast factor and compact low-profile housing

Compliance & Certifications

• FCC 47 CFR Part 18 Non-Consumer
• RoHS compliant
• UL Type 1 Outdoor
• UL Type CC

ADL Supply recommends confirming lamp type, ballast factor, and housing dimensions before ordering or installation.

Safety & Installation Notes

• Disconnect power before installation or service.
• Use only with compatible lamp configurations.
• Verify input voltage before installation.
• Confirm ballast fit within the fixture channel before ordering.
• Follow fixture manufacturer instructions and local electrical codes.
