GE GE332MAX480-H Electronic Ballast – 480V | Instant Start | High Ballast Factor 1.18 | UltraMax® | 3-Lamp T8 High Output

High-performance 480V electronic ballast with high ballast factor (1.18) for increased light output – designed for industrial and commercial fluorescent lighting systems requiring 3-lamp T8 operation.

Quick Specs

• Brand: GE Lighting
• Series: UltraMax®
• Model: GE332MAX480-H
• Ballast Type: Electronic Fluorescent Ballast
• Input Voltage: 480V, 60Hz
• Lamp Count: 3 Lamps
• Lamp Compatibility: F17T8, F25T8, F28T8, F32T8 and equivalent T8 lamps
• Ballast Factor: 1.18 (High Output)
• Efficiency: >90%
• Minimum Starting Temperature: -20°F
• Max Case Temp: 70°C
• Sound Rating: Class A (20-24 dB)
• Dimensions: 9.5" L x 1.3" W x 1.2" H
• Compliance: UL Type 1 Outdoor, UL Type CC, FCC Part 18, RoHS
• Additional Features: Anti-Striation Control, Active Current Regulation

Product Overview

The GE332MAX480-H is a 480V high-output electronic ballast designed for 3-lamp T8 fluorescent systems. With a 1.18 ballast factor, it delivers increased light output compared to standard-output models, making it ideal for industrial and high-ceiling applications.

This ballast is designed for 480V electrical systems, commonly used in industrial facilities and large commercial installations.

Why Choose This Product

• High light output: 1.18 ballast factor increases brightness
• 480V compatibility: Built for industrial systems
• 3-lamp configuration: Ideal for higher lumen applications
• Reliable instant start: Suitable for general fluorescent lighting
• Improved light quality: Anti-striation circuitry reduces flicker
• Compact design: Fits standard ballast channels

Applications

• Industrial facilities
• Warehouses and high-bay lighting
• Commercial buildings with 480V systems
• High-output fluorescent retrofit projects

Compatibility & Replacement

Designed for: 3-lamp T8 fluorescent systems operating on 480V.

Important: This is a high ballast factor (1.18) model. Do not substitute with 0.77 or 0.87 ballast factor versions unless reduced light output is acceptable.

Compliance & Certifications

• UL Listed
• RoHS Compliant
• FCC Part 18
• UL Type 1 Outdoor
• UL Type CC

ADL Supply recommends confirming voltage (480V), lamp count, and ballast factor before ordering.
