GE 67566 GE454MVPS90F – 3 or 4 Lamp F54T5HO Electronic Ballast | 120–277V | Programmed Rapid Start

The GE 67566 GE454MVPS90F is an electronic T5 high-output ballast designed to operate three or four compatible F54T5HO fluorescent lamps. It accepts 120–277V input, uses programmed rapid-start operation, and provides parallel lamp wiring. The ballast has a normal ballast factor and is intended for compatible commercial and industrial T5HO fixtures. Please verify the complete ballast model, lamp type, lamp quantity, input voltage, wiring diagram, dimensions, and fixture compatibility before ordering.

Lamp Quantity

3 or 4

T5HO Lamps

Input Voltage

120–277V

Multi-Volt

Start Type

Programmed

Rapid Start

Lamp Wiring

Parallel

Electronic

Warranty

5 Years

Limited Warranty

Technical Specifications

Brand	GE Lighting
Product Code	67566
Model Number	GE454MVPS90F
Product Type	T5 high-output electronic fluorescent ballast
Technology Type	Traditional
Compatible Lamp Type	Compatible F54T5HO fluorescent lamps
Lamp Quantity	Three or four lamps
Input Voltage	120–277V
Starting Method	Programmed rapid start
Lamp Wiring	Parallel
Ballast Factor	Normal
Overall Length	16.75 in
Width	1.8 in
Height	1.2 in
Weight	3.0 lb
Warranty	Five-year limited warranty
Standard Pack Quantity	10 ballasts
UPC	043168675666

Key Features & Benefits

Designed to operate three or four compatible F54T5HO fluorescent lamps.
120–277V input supports common commercial electrical systems.
Programmed rapid-start operation for compatible T5HO fixtures.
Parallel lamp wiring configuration.
Normal ballast factor for standard light-output applications.
Low-profile housing measuring approximately 1.8 inches wide and 1.2 inches high.
Covered by a five-year limited manufacturer warranty.

Product Overview

The GE 67566 GE454MVPS90F is designed for commercial T5 high-output fluorescent fixtures that use three or four compatible lamps. Its multi-volt 120–277V input allows use across common commercial branch-circuit voltages without requiring separate ballast models for each listed voltage.

The programmed rapid-start circuit is intended to provide controlled lamp starting in compatible fluorescent systems. Parallel wiring means the ballast uses the lamp configuration shown in the manufacturer wiring diagram and must not be wired as a series ballast.

This ballast should be selected by exact model number and lamp configuration. Similar GE ballast model numbers may have different lamp counts, ballast factors, wiring layouts, case dimensions, or starting methods.

Compatible Applications

Three-lamp F54T5HO fluorescent fixtures
Four-lamp F54T5HO fluorescent fixtures
Commercial T5 high-output lighting systems
Warehouse and industrial fluorescent fixtures
Institutional and retail lighting systems
Maintenance replacement where GE454MVPS90F or GE product code 67566 is specified

Before Ordering – Verify

Product code: Confirm the required GE product code is 67566.
Model number: Verify the complete model GE454MVPS90F.
Lamp quantity: This ballast is specified for three or four lamps, not one or two lamps.
Lamp type: Confirm the fixture uses compatible F54T5HO fluorescent lamps.
Input voltage: Verify the branch circuit is within the specified 120–277V range.
Starting method: Confirm the fixture requires programmed rapid-start operation.
Wiring: Compare the existing wiring with the manufacturer’s parallel-wiring diagram before removing the original ballast.
Ballast factor: Confirm that a normal ballast factor is correct for the fixture and required light output.
Dimensions: Verify the available mounting space accepts a ballast approximately 16.75 inches long, 1.8 inches wide, and 1.2 inches high.
Weight: Confirm the fixture can support a 3.0-pound ballast.
Cross-references: Do not substitute another brand or ballast solely from a cross-reference number without confirming lamp count, wiring, dimensions, ballast factor, and electrical specifications.

Safety and Installation Guidelines

Disconnect and lock out electrical power before inspecting, wiring, installing, or removing the ballast.
Follow the wiring diagram printed on the ballast label or supplied by the manufacturer.
Use only with approved lamp types and lamp quantities.
Do not connect one or two lamps to this ballast.
Ground the ballast and fixture according to applicable electrical codes and manufacturer instructions.
Cap all unused conductors individually with approved electrical connectors.
Do not install a ballast with damaged wiring, housing, or insulation.
Verify all connections before restoring power.
Installation should be completed by qualified electrical personnel.

Compliance

The current manufacturer page references safety certifications but does not identify the specific certification marks in the supplied printable sheet.
No verified UL Type 1 Outdoor, Class P, Type HL, RoHS, FCC, DLC, ENERGY STAR, Title 20, Title 24, or JA8 claim is included in this listing.
No verified mercury-content statement applies to the ballast from the supplied manufacturer sheet.
