GE432MVL (GE432MAX-G-L) ProLine UltraMax-L 4-Lamp T8 Ballast – 120-277V | Low Ballast Factor 0.77 | Instant Start

Energy-saving electronic ballast designed for 3-4 lamp T8 systems, reducing light output and energy consumption with a 0.77 ballast factor.

Compatible Lamps

• (3-4) F17T8/ECO 24in
• (3-4) F25T8/ECO 36in
• (3-4) F32T8 32W Standard
• (3-4) F32T8 Energy Saving (25W, 28W, 30W)
• U-Bend T8 Equivalent Lamps
• (3) FO40 60in lamps (specific wiring configuration only)

Product Overview

The GE432MVL (GE432MAX-G-L) is a low-output electronic ballast designed for 3 to 4 lamp T8 fluorescent systems. With a 0.77 ballast factor, it reduces energy consumption while providing adequate illumination for general applications.

Additional Information

• High efficiency electronic ballast (>90%)
• Instant start operation
• Multi-Voltage Technology (120-277V)
• Parallel circuitry – lamps remain lit if one fails
• Anti-striation circuitry improves light quality
• Minimum starting temperature: -20°F
• Max case temperature: 70°C
• Low profile housing: 9.5" L x 1.3" W x 1.2" H
• Sound Rating: Class A (20-24 dB)
• FCC Part 18 compliant
• RoHS compliant
• UL Type 1 Outdoor rated

Applications

• Energy-saving retrofit projects
• Commercial lighting systems
• Office and retail environments
• Areas where reduced light levels are acceptable

Cross Reference

• Universal B432IUNVEL-A
• Sylvania QTP4X32T8/UNV ISL-SC
• Philips Advance IOP-4P32-LW-SC

Important: This is a low ballast factor (0.77) ballast. Do not substitute with 0.87 or 1.18 models unless higher light output is required.
