GE UltraMax eHID 70W Electronic Metal Halide Ballast - 120V ANSI M98/M143 Outdoor Rated

Specifications

Advanced Technology & Protection Features

• End-of-Lamp-Life Protection: Automatically shuts down when lamp reaches end of useful life, preventing ballast damage and safety hazards
• Thermal Protection: Built-in over-temperature safeguard prevents overheating and extends component lifespan
• Low Frequency Operation: Reduces lamp stress and extends metal halide lamp life compared to high-frequency ballasts
• Recessed Fixture Compatible: Compact design fits tight spaces in downlights and recessed housings
• Outdoor-Rated Enclosure: Weather-resistant construction withstands rain, snow, humidity, and temperature extremes
• Ignitor Integrated: Built-in ignitor eliminates need for separate starting components
• Quick Restrike: Faster lamp restrike after brief power interruptions (compared to magnetic ballasts)

Professional-Grade Electronic HID Ballast for Commercial & Industrial Outdoor Lighting Systems

Compatible Metal Halide Lamps (ANSI Standards)

This electronic ballast is specifically designed to operate the following ANSI-rated metal halide lamps:

• ANSI M98 - 70W metal halide lamps (standard probe-start)
• ANSI M143 - 70W metal halide lamps (alternate configuration)

⚠️ Important: NOT compatible with High Pressure Sodium (HPS) lamps. Verify ANSI code on lamp before installation.

Safety Certifications & Standards Compliance

• CU-UL Listed: Certified for both US (UL) and Canadian (cUL) electrical safety standards
• NEMA Type 1 Outdoor: Approved for outdoor installation in protected locations
• NEMA 3R Compliant: Weather-resistant enclosure protects against rain, sleet, and snow
• IP65 Equivalent Protection: Dust-tight and protected against water jets from any direction
• FCC Part 18 Compliant: Meets electromagnetic interference (EMI/RFI) standards
• RoHS Compliant: Lead-free, environmentally responsible construction
• Class P Thermally Protected: Self-resetting thermal protection prevents overheating

Ideal Applications & Commercial Use Cases

The GE UltraMax 70W electronic ballast is engineered for professional installations requiring reliable metal halide lighting:

Outdoor Lighting Applications

• Parking Lot & Garage Lighting: Reliable operation in all weather conditions
• Building Perimeter & Security Lighting: Cold-weather starting down to -20°C
• Walkway & Pathway Illumination: Energy-efficient outdoor lighting
• Canopy & Soffit Lighting: Protected outdoor locations

Sports & Recreation Facilities

• Stadium Floodlights: High-performance sports lighting systems
• Arena Lighting: Reliable illumination for indoor/outdoor venues
• Athletic Field Lighting: Professional sports facility illumination
• Tennis Court Lighting: Precision illumination for recreational facilities

Industrial & Commercial Facilities

• Warehouse High Bay Fixtures: Industrial interior lighting (recessed compatible)
• Manufacturing Plant Lighting: Reliable operation in demanding environments
• Loading Dock Illumination: Weather-resistant outdoor/indoor transition areas
• Cold Storage Facilities: Sub-zero starting capability

Architectural & Specialty Applications

• Landscape Accent Lighting: Architectural feature illumination
• Monument & Façade Lighting: Professional outdoor architectural lighting
• Flag Pole Lighting: Uplight applications
• Sign Illumination: Commercial signage lighting systems

Installation Requirements & Guidelines

Pre-Installation Checklist

• Verify Lamp Compatibility: Confirm lamp ANSI code matches M98 or M143 rating
• Check Input Voltage: Ensure 120V supply voltage (NOT compatible with 208V, 240V, or 277V)
• Confirm Fixture Rating: Verify fixture is rated for electronic ballasts
• Review Wiring Diagram: Follow wiring diagram on ballast label exactly
• Inspect Enclosure: Ensure junction box and fixture provide adequate ventilation

Critical Installation Notes

• Mount ballast in well-ventilated location to prevent overheating
• Do not exceed maximum ambient temperature of 50°C (122°F)
• Use minimum 18 AWG wire for all connections (THHN rated for high temperature)
• Ensure all wire connections are secure and properly insulated
• Ground ballast enclosure according to NEC requirements
• For outdoor installations, ensure fixture provides NEMA 3R or better protection
• Install within rated recessed fixture clearances if used in downlights

Safety Warnings

• ⚠️ Electric Shock Hazard: Disconnect power before installation or servicing
• ⚠️ Incompatible Lamps: NOT for use with High Pressure Sodium (HPS) lamps - will damage ballast
• ⚠️ Overheating Risk: Do not cover ballast or restrict airflow around enclosure
• ⚠️ Voltage Mismatch: 120V only - do not connect to 208V, 240V, or 277V circuits

Electronic vs. Magnetic Ballast Advantages

GE UltraMax electronic ballasts offer significant performance benefits compared to traditional magnetic (core-coil) ballasts:

• Energy Efficiency: 10-15% lower energy consumption reduces operating costs
• Lighter Weight: 60% lighter than magnetic ballasts - easier installation
• Cooler Operation: Less heat generation extends fixture and lamp life
• Faster Restrike: Quicker lamp restart after power interruptions
• Cold Weather Starting: Reliable ignition down to -20°C vs. -30°C for magnetic
• Lamp Life Protection: End-of-life shutdown prevents lamp cycling damage
• Compact Size: Smaller footprint fits more fixture types including recessed

Maintenance & Troubleshooting Guide

Routine Maintenance

• Inspect ballast and fixture quarterly for signs of overheating or damage
• Clean fixture lenses and reflectors to maintain light output
• Check wire connections annually for tightness and corrosion
• Replace lamps at 75% of rated life to prevent end-of-life ballast shutdown
• Keep ballast enclosure area clear of debris and obstructions

Common Troubleshooting

Lamp Won't Start

• Verify power supply is energized (120V)
• Check lamp is properly seated in socket
• Confirm lamp ANSI code matches M98 or M143
• Test with known good lamp to rule out lamp failure
• Inspect wire connections for looseness or damage

Lamp Flickers or Cycles On/Off

• Replace lamp - likely at end of rated life
• Check for loose connections at lamp socket
• Verify ballast is not overheating (check ventilation)
• Confirm voltage stability at ballast input

Ballast Shuts Down Automatically

• End-of-lamp-life protection activated - replace lamp
• Thermal protection triggered - improve ventilation, reduce ambient temperature
• Short circuit detected - inspect wiring for damage

Reduced Light Output

• Lamp lumen depreciation - replace aged lamp
• Clean fixture reflector and lens
• Verify input voltage is stable 120V ±10%

Energy Efficiency & Cost Savings

Upgrading from magnetic to GE UltraMax electronic ballasts delivers measurable energy and cost benefits:

• Lower Energy Consumption: Electronic ballasts consume 8-12 watts less than magnetic equivalents
• Reduced HVAC Load: Less heat generation lowers cooling costs in conditioned spaces
• Extended Lamp Life: Low-frequency operation and end-of-life protection maximize lamp operating hours
• Faster ROI: Energy savings typically recover ballast upgrade costs within 2-3 years
• Lower Maintenance: Longer lamp life reduces replacement labor and disposal costs
• Utility Rebate Eligible: Many utility companies offer rebates for electronic ballast retrofits (check local programs)

Product Warranty & Support

Manufacturer Warranty: GE Lighting provides a comprehensive warranty on this ballast. Contact GE Commercial Lighting or your authorized distributor for complete warranty terms, registration, and technical support.

Technical Support: For installation assistance, troubleshooting, or product questions, contact GE Lighting Technical Services or visit the GE Lighting professional support website.

Cross-Reference & Alternative Ballasts

Comparable electronic ballasts for 70W metal halide applications:

• Philips Advance REM-70-S: 70W metal halide electronic ballast, similar specs
• Sylvania 51420: QuickTronic 70W MH electronic ballast
• Howard Lighting EP1/70MH/120/277: Multi-volt option (not direct replacement - verify voltage)

Note: Always verify ANSI lamp compatibility, voltage rating, and physical dimensions before substituting ballasts.

✓ Energy-Efficient Electronic Technology

Electronic ballast technology reduces energy consumption by up to 15% compared to magnetic ballasts while extending lamp life and improving light quality. Ideal for energy-conscious facility upgrades and new construction projects.
