Sylvania 49467 QHE4X32T8/347 ISN-SC

(No reviews yet) Write a Review
$78.64
SKU:
SFB49467
Availability:
Lead Time 3-10 Business Days To Ship
Shipping:
Calculated at Checkout

Product Overview


Sylvania Quicktronic High Effiency QHE 4X32T8/347 ISN-SC Normal Ballast Factor 347V Fluorescent T8 Ballast

Operates the Following Fluorescent Lamps:

  • (1) FO17 24in Fluorescent Lamp
  • (1) FO25 36in Fluorescent Lamp
  • (1) FO32/25W 48in Energy Saving F32T8 25W Lamps
  • (1) FO32/28W 48in Energy Saving F32T8 28W Lamps
  • (1) FO30/SS (48in Energy Saving F32T8 30W Advantage Lamps)
  • (1) F32T8 (48in FO32/ECO 32W Standard Lamps)
  • (1) FBO16,FBO24, FBO29/SS, FBO30/SS, FBO31,FBO32 U-Bend Lamps
  • (1) FO40 60in Fluorescent T8 Lamp
  • Ballast Factor 0.88

Additional Information:

  • 70C Max Case Temperature
  • UL Listed Class P, Type 1 Outdoor
  • Ground ballast case
  • Lampholder must be shorted per diagram
  • Install in accordance with National Electric Codes
  • Complies with FCC 47 CFR Part 18, Non-Consumer
  • ANSI 62.41 Cat. A Transient Protection
  • Class A Sound Rating.
  • Input Frequency: 50/60Hz.
  • Complies with UL935 requirements for "Type CC" rating
  • Minimum starting temperature: 60 F / 16 C with SS lamps
  • Minimum starting temperature: -20 F / -29 C
  • CSA certified.
  • ANSI C82.11 where applicable.
  • NO PCB (Polychlorinated Biphenyl)
  • Remote mounting up to 20 feet Lamp Striation Control (LSC) may minimize
  • Or eliminate lamp striations which can occur in T8 energy savings lamps.
  • Small Can Enclosure Design (Dim:9.47”L x 1.69”W x 1.18”H)
  • Minimum starting temperature: -20 F / -29 C
  • Complies with FCC 47 CFR Part 18, Non-Consumer
  • Normal Ballast Factor < 10% THD
  • Dual Voltage 120-277V 50/60Hz
  • Circuit Type Parallel
  • Meet NEMA Premium Electronic M Ballast Program Requirements and qualify for utility incentives
  • Deliver 30-60% energy savings when D compared to F34T12 magnetically ballasted systems
  • Offer up to 6% (2-5 Watt) energy O savings over standard electronic ballasts
  • Achieve over A 100 (LPW) with OCTRON® 800 XP® SUPERSAVER® lamps
  • Available in: A – Instant Start and PROStart® (Programmed Rapid Start)
  • Bi-level QUICKSTEP® and POWERSENSE® Dimming models
  • Excellent for The Most Stringent energy codes and sustainability focused projects

 Cross Reference:

  • Universal B232IUNVEL-A
  • GE-232-MAX-L/ULTRA
  • Advance IOP-2P32-LW-SC
  • Keystone KTEB-232-UV-IS-L-P
