Sylvania 21112 CF18DD/830/ECO 18W 3000K G24d-2 2-Pin CFL

Product Overview

Sylvania 21112 CF18DD/830/ECO – 18W DULUX® D 2-Pin CFL | 3000K | 1150 Lumens | G24d-2

The Sylvania 21112 CF18DD/830/ECO is a 18-watt DULUX® D double-twin-tube 2-pin compact fluorescent lamp with a G24d-2 base. It produces 1150 initial lumens at 3000K with a CRI of 82 and carries an average rated life of 10,000 hours. It has a starter in the lamp base for magnetic ballast operation. Manufacturer cross-reference: GE F18DBXT4/SPX30; Philips PL-C 18W/830. Before ordering, verify the exact item number, wattage, base, ballast compatibility, color temperature, and physical dimensions.

Wattage

18W

DULUX® D 2-Pin

Initial Lumens

1150

990 Mean lm

Color Temp

3000K

CRI 82

Base

G24d-2

2-Pin Plug-In

Rated Life

10,000 hrs

At 3 Hours/Start

Technical Specifications

Brand	Sylvania / LEDVANCE
Item Number	21112
Ordering Abbreviation	CF18DD/830/ECO
NEMA Generic Designation	CFQ18W/G24d/830
Lamp Family	DULUX® D 2-Pin Preheat Compact Fluorescent
Wattage	18W
Base Type	G24d-2 2-Pin (starter in lamp base)
Bulb	D (T4)
Initial Lumens	1,150 lm (at 25°C / 77°F)
Mean Lumens	990 lm
Color Temperature	3000K
Color Rendering Index	82
Average Rated Life	10,000 hours, based on 3 hours per start
Maximum Overall Length (MOL)	6.0 in (153 mm)
Package Quantity	50
Minimum Starting Temperature	5°F

Cross Reference

Sylvania Item Number	21112
Sylvania Ordering Abbreviation	CF18DD/830/ECO
NEMA Generic Designation	CFQ18W/G24d/830
GE Equivalent	F18DBXT4/SPX30
Philips Equivalent	PL-C 18W/830

Cross-reference codes are taken from the manufacturer catalog. Confirm wattage, base, color temperature and ballast compatibility before substituting a different brand.

Product Overview

DULUX® D preheat 2-pin lamps have an internal starter in the lamp base and are designed for preheat, magnetic ballast operation. This lamp is not a self-ballasted screw-in CFL and is not a 4-pin lamp.

Per the manufacturer catalog, 2-pin compact fluorescent lamps are not suitable for frequently cycled applications or for use with occupancy sensors.

Compatible Applications

Fixtures and magnetic preheat ballasts designed for 18W G24d-2 2-pin compact fluorescent lamps
Commercial and residential recessed, wall-mounted and surface-mounted fixtures designed for this lamp type

Before Ordering – Verify

Item number: Confirm Sylvania 21112.
Ordering abbreviation: Confirm CF18DD/830/ECO.
Base: Verify the lampholder is G24d-2 (2-pin).
Wattage: Confirm the fixture ballast is designed for 18W compact fluorescent lamps.
Ballast: 2-pin lamps have an internal starter and are for magnetic preheat operation. Do not install in a 4-pin socket.
Color: This version is 3000K, CRI 82.
Dimensions: Confirm the 6.0 in (153 mm) maximum overall length fits the fixture.
Cycling and sensors: Not suitable for frequently cycled applications or occupancy sensors.
Cross reference: GE and Philips codes are manufacturer-catalog equivalents; verify fit and ballast compatibility before substituting.

Safety and Handling Guidelines

Disconnect electrical power before installing or removing the lamp.
Use only with a compatible ballast and lampholder.
Never install a 2-pin lamp in a 4-pin socket, even if the lamp fits.
Handle the glass tubes carefully and do not install cracked or damaged lamps.
Allow the lamp and fixture to cool before servicing.
This lamp contains mercury. Dispose of used lamps according to local, state and federal regulations; see www.lamprecycle.org.

Compliance

SYLVANIA ECOLOGIC® lamp designed to pass the Federal TCLP criteria for classification as non-hazardous waste in most states; disposal regulations may vary, so check local and state regulations.
Initial lumens are approximate values after 100 hours of operation.
Average rated life is based on 3-hour burning cycles under specified conditions with a ballast meeting ANSI specifications.
Mercury-containing lamp; follow applicable disposal and recycling regulations.
