GE LED Plug-In Type A GX24q Vertical 18.5W 3000K - LED19GX24q-V/830

GE LED19GX24Q-V/830 39277 — 18.5W LED Type A Plug-In Lamp, Vertical, 3000K, GX24q 4-Pin

The GE LED19GX24Q-V/830 (Order Code 39277) is an 18.5-watt LED Type A plug-in lamp from GE/Current Lighting Solutions, designed as a direct retrofit replacement for 32W or 42W pin-based compact fluorescent lamps. This vertical-orientation lamp operates on a compatible existing electronic CFL ballast — no rewiring or ballast bypass required. With a GX24q 4-pin base, fixed 3000K warm white color temperature, 80 CRI, 1,850 initial lumens, 100 LPW efficacy, and a rated life of 50,000 hours, this lamp delivers significant energy savings and reduced maintenance versus legacy CFL lamps. cULus and DLC certified, Damp location rated. Sold 6 per carton. Verify ballast compatibility before ordering.

Technical Specifications

Product Overview

The GE LED19GX24Q-V/830 is a Type A 4-pin LED plug-in lamp, meaning it operates directly from an existing compatible electronic CFL ballast — no ballast bypass, rewiring, or new driver installation is required for a qualifying retrofit. At 18.5W, this is GE's higher-output Type A lamp, designed to replace 32W or 42W CFL lamps rather than the 13–26W range covered by the 9W lamps in this family. This is a fixed-color-temperature model set permanently at 3000K warm white.

With 1,850 initial lumens at 100 LPW efficacy and a rated life of 50,000 hours, this lamp is backed by a 5-year limited warranty. This vertical orientation is purpose-built for fixtures that mount the lamp perpendicular to the ceiling or mounting surface (such as recessed downlights). A closely related sibling SKU (39279, 4000K) exists in this same 18.5W vertical family with different photometric specs — confirm the correct color temperature before ordering, since these are separate, non-interchangeable part numbers despite sharing the same wattage and base type.

Compatible Applications

• Compact fluorescent retrofit projects — Direct replacement for 32W or 42W 4-pin CFL lamps in existing vertical-mount fixtures with compatible electronic ballasts.
• Hospitality and retail lighting — Warm 3000K CCT suits inviting commercial environments.
• Higher-output retrofit applications — 18.5W/1850lm output suits fixtures previously using higher-wattage CFL lamps where the 9W lamps in this family would underperform.
• Damp locations — Rated for damp interior or partially protected exterior locations.

Before Ordering — Verify

• Ballast Compatibility: This lamp requires a compatible electronic CFL ballast.
• Orientation: Confirm your fixture requires a vertical orientation lamp.
• Existing CFL Wattage: Confirm you are replacing a 32W or 42W 4-pin CFL lamp — this is not the correct lamp for 13–26W CFL replacements (see GE's 9W lamp family instead).
• Color Temperature: This lamp is fixed at 3000K — confirm this is correct, since a 4000K sibling (order code 39279) exists in this same wattage/base family and is a different, non-interchangeable part number.
• Physical Fit: Confirm 6.4" MOL and 1.1" diameter fit within your fixture's lamp compartment.
• DLC Status: Verify current DLC QPL qualification at designlights.org/search if required for a utility rebate program.
• Carton Quantity: Minimum order quantity is 6 units (1 carton).

Safety and Handling Guidelines

• Disconnect power before installing or replacing the lamp.
• Electronic Ballast Required: Confirm ballast compatibility before installation.
• Damp Location Use: Confirm fixture rating matches installation environment.

Compliance

• cULus listed. DLC certified — verify current QPL status at designlights.org/search.
• RoHS compliant — contains no lead or mercury. No mercury-related shipping restrictions apply.
• 5-year limited warranty.

Ordering Information

• Brand: GE / Current Lighting Solutions
• GE Order Code / SKU: 39277
• Manufacturer Part Number: LED19GX24Q-V/830
• UPC: 043168392778
• Wattage: 18.5W
• Base: GX24q (4-Pin, Vertical)
• Color Temperature: 3000K (Fixed)
• Packaging: 6 per carton.
• Case quantities and bulk pricing: Contact ADL Supply for volume orders.

For wholesale pricing, bulk availability, or help confirming the correct replacement lamp, contact ADL Supply at 1-800-235-3489.
