Product Overview

Ushio 1000822 JC12V-20W G6.35 Halogen Bi-pin Lamp – 20W | 12V | 2850K Warm White | G6.35 Miniature Bi-Pin

The Ushio 1000822 JC12V-20W G6.35 Halogen Bi-pin Lamp is a 20W 12V halogen miniature lamp with G6.35 Miniature Bi-Pin base, 2850K Warm White color temperature, CRI 100, 2,000 hours rated life.

Wattage

20W

Halogen JC M

Voltage

12V

Operating

Color Temp

2850K

CCT

Lumens

—

Initial lm

Rated Life

2,000

Hours

Quick Specs

Brand: Ushio
Ushio Catalog Number: 1000822
Lamp Type: Halogen JC Miniature — G6.35/GY6.35 Bi-Pin
Wattage: 20W
Operating Voltage: 12V
Color Temperature: 2850K Warm White
CRI: 100
Rated Average Life: 2,000 hours
Base Type: G6.35 Miniature Bi-Pin
Overall Length (MOL): 1.73in x DIA 43mm
Burn / Operating Position: Position

Product Overview

The Ushio 1000822 JC12V-20W G6.35 Halogen Bi-pin Lamp is a 20W 12V halogen miniature lamp with G6.35 Miniature Bi-Pin base for instrument lighting, task lighting, fiber optic illuminators, and specialty optical applications. At 2850K Warm White with CRI 100 this lamp provides high-quality illumination. Rated life: 2,000 hours.

Do not touch the quartz envelope with bare hands.

Applications

Instrument lighting — Instrument lighting, task lighting, fiber optic illuminators, and specialty optical applications.
Retrofit and maintenance replacement – Confirm lamp type, wattage, voltage, and base before ordering.

Safety and Handling

Do not touch the lamp envelope with bare hands. Skin oils cause hot spots leading to premature failure. Use clean gloves or lint-free cloth.
Voltage — 12V: Verify supply matches rated voltage.
Enclosed fixture only. Use only in approved enclosed fixtures.
Allow 15-minute cool-down before replacement.
