KLS KHD 1800/DE Double-Ended Metal Halide Lamp 1800W 6000K SFc15.5-6

The KHD 1800/DE is a KLS ac metal halide lamp rated at 1800W, 6000K, 100V lamp voltage, 155000 lm total flux, 750 h average life, and SFc15.5-6 base.

Quick Specs

• Brand: KLS
• Lamp Type / SKU: KHD 1800/DE
• Family: AC Metal Halide Lamp
• Voltage: 100V
• Wattage: 1800W
• Total Flux: 155000 lm
• Color Temperature: 6000K
• Average Life: 750 h
• Burning Position: ANY
• Base: SFc15.5-6
• Figure Reference: Fig. 1
• Additional Details: Double-ended | A:220 mm | B:18.0±1 mm | C:10±0.5 mm | D:⌀26±0.5

Applications

Suitable for specialized HID and metal halide lighting applications where the listed electrical, mechanical, and burning-position requirements must be matched to the fixture and power supply.

Notes

Verify fixture compatibility, base, operating orientation, and electrical characteristics before ordering.
