Sollos BSB067-AB-MR16FL6/RGBW/LED 24803S Straight Bullet Antique Brass

Sollos BSB067-AB-MR16FL6/RGBW/LED (24803S) Straight Bullet – Antique Brass

The Sollos BSB067-AB (product number 24803S) is a 12V AC low-voltage straight bullet with a stake-mount body, finished in Antique Brass. It uses a clear tempered glass and a MR16 GU5.3 bi-pin socket rated for lamps up to 50W, and ships with 3 ft. 18-2 lead wire. This is a kitted assembly supplied with a Sollos ProLED MR16FL6/RGBW/LED GU5.3 lamp installed (RGB / 2700K White, 35W-equivalent). Confirm finish, socket type, and transformer capacity before ordering.

Technical Specifications

Product Overview

The Sollos Straight Bullet is finished in Antique Brass UV- and corrosion-resistant powder coat over cast brass, natural copper, or stainless steel. It uses clear tempered glass and a MR16 GU5.3 bi-pin socket rated for lamps up to 50W.

This order code is supplied as a kitted assembly with a Sollos ProLED MR16FL6/RGBW/LED lamp installed (6W, 35W-equivalent, RGB / 2700K White, 400 lumens). The fixture-only version of the same configuration is sold under a separate order code. The fixture operates on a 12V AC landscape transformer ordered separately.

Compatible Applications

• Uplighting trees, columns, and architectural facades
• Accent lighting for shrubs and garden features
• Residential and commercial landscape lighting on a 12V AC circuit

Before Ordering – Verify

• This is a 12V AC low-voltage fixture. It will be destroyed if connected to 120V line voltage. A 12V landscape transformer is required and is not included.
• Socket is MR16 GU5.3 bi-pin. Confirm any replacement lamp uses the same base – MR16 GU5.3, G4/GY6.35, MR11 GU4, and PAR36 MP-terminal lamps are not interchangeable.
• This order code includes an LED lamp. If you need the fixture without a lamp, order the fixture-only version of the same configuration instead.
• Confirm finish: this item is Antique Brass. Antique Brass, Natural Copper, Stainless Steel, and Composite Black finishes carry a lifetime warranty; Textured Black and Textured Bronze carry a 5-year warranty.
• Total the wattage of every fixture on the run and size the transformer accordingly, allowing headroom for future additions.
• ProLED lamps may not be compatible with every dimming system; test on the actual circuit before completing a full installation.

Safety and Handling Guidelines

• De-energize the transformer before wiring, relamping, or servicing the fixture.
• Bury or otherwise protect the low-voltage cable run to prevent damage from mowers, edgers, and digging.
• Do not exceed the 50W maximum lamp rating. Overlamping causes excess heat, socket damage, and lens degradation.
• Keep the lens clear of mulch, soil, and dense foliage so heat can dissipate.
• This fixture contains no mercury; LED lamps are mercury-free.

Compliance

• ETL Listed to UL 1838 (Low Voltage Landscape Lighting Systems) and CSA C22.2 No. 250.7.
• Intended for use on Class 2 / low-voltage landscape lighting circuits supplied by a listed 12V landscape transformer.
• Install in accordance with the National Electrical Code and all applicable local codes; NEC Article 411 governs low-voltage lighting systems.
• Mercury-free product. RoHS-compliant construction.
• All specifications are subject to change by the manufacturer; the current Sollos published specification governs.

Ordering Information

• Order code: BSB067-AB-MR16FL6/RGBW/LED  |  Sollos product number: 24803S  |  ADL Supply SKU: SOLL24803S
• Configuration: Straight Bullet, Antique Brass, 12V AC, MR16 GU5.3 bi-pin, 50W max.
• Supplied with a Sollos ProLED MR16FL6/RGBW/LED lamp (product 82099) installed, 6W, RGB / 2700K White, 400 lumens.
• Mounting: 8" ground stake included.
• Warranty: Lifetime limited warranty on Antique Brass finish.

For wholesale pricing, bulk availability, or help confirming the correct replacement lamp, contact ADL Supply at 1-800-235-3489.
