Product Overview
Halco 87201 48T8HE-10-840-DSE-BYP-LED – 10.5W | 4000K Cool White | 1,680 Lumens | G13 Medium Bi-Pin
The Halco 87201 48T8HE-10-840-DSE-BYP-LED is a 10.5W 4000K Cool White LED lamp delivering 1,680 initial lumens, CRI 83, G13 Medium Bi-Pin base, and 50,000-hour rated life.
| Wattage 10.5W LED | Color Temp 4000K Cool White | Lumens 1,680 Initial lm | Rated Life 50,000 Hours | Base Type G13 Medium Bi-Pin |
Quick Specs
- Brand: Halco (ProLED)
- Lamp / Bulb Type: 48-inch T8 Type B (Ballast Bypass) Linear LED Lamp
- Wattage: 10.5W
- Equivalent Fluorescent: 32W
- Voltage: 120-277V
- Color Temperature: 4000K Cool White
- CRI: 83
- Initial Lumens: 1,680 lm
- Rated Average Life: 50,000 hours
- Base Type: G13 Medium Bi-Pin
- Length: 48 in (nominal)
- Dimmable: Only with an external dimming driver
Product Overview
The Halco 87201 48T8HE-10-840-DSE-BYP-LED is a 10.5W 48-inch T8 Type B (Ballast Bypass) Linear LED Lamp. It is a Type B ballast-bypass lamp that runs on line voltage after the fluorescent ballast is removed or bypassed. It is suited to hospitality, retail, offices, educational facilities, and medical facilities. Equivalent to a 32W fluorescent. Rated life: 50,000 hours. CRI 83. Verify with data sheet for additional specs.
Applications
- Residential, commercial, and industrial lighting – Hospitality, retail, offices, educational facilities, and medical facilities.
- Fluorescent-to-LED retrofit – Replacement for existing fluorescent lamps of the same length and base when installed per the manufacturer instructions.
Ordering Information
- Brand: Halco
- P/N: 87201
- Item Code: 48T8HE-10-840-DSE-BYP-LED
- UPC: 807154872015
- Wattage / CCT: 10.5W / 4000K Cool White
- Base: G13 Medium Bi-Pin
- Standard packaging (per Halco catalog): 25/25. Contact ADL Supply for volume orders.
- Before ordering – verify: Type B: the existing fluorescent ballast must be removed or bypassed and the fixture wired per the installation instructions; confirm the lampholder type (shunted or non-shunted) against the instructions. Dimming: Only with an external dimming driver. Confirm dimmer or driver compatibility before use. Confirm your fixture accepts the G13 Medium Bi-Pin base and 48-inch length.
Compliance
- Verify RoHS / TCLP compliance with manufacturer specification sheet.
- UL Listed (per Halco product information).
- DLC Qualified (per Halco product information) – check the DesignLights Consortium list for the exact listing.
- FCC compliance noted in Halco product information.
ADL Supply recommends confirming all specifications with the manufacturer product data sheet prior to installation. For wholesale pricing and bulk availability, call ADL Supply at 1-800-235-3489.
