Product Overview
Sylvania Vapor Tight Jelly Jar LED 10W Ceiling Mount Light Fixture - 4000K Cool White , Gray, 120-277V
Quick Overview: A durable, commercial-grade Jelly Jar style LED ceiling light fixture from SYLVANIA. This 10W, 900-lumen LED provides 5000K daylight white illumination in a gray, powder-coated die-cast aluminum housing. Rated for 150,000 hours and suitable for wet locations. Perfect for exterior, industrial, and commercial mounting.
Product Description
The SYLVANIA Jelly Jar LED Ceiling Light is a high-efficiency, long-life solution for demanding environments. This fixture features a classic jelly jar design with a modern frosted glass lens and universal voltage input (120-277V), making it an ideal retrofit or new construction choice for corridors, stairwells, warehouses, building entrances, and exterior overhangs. Its robust construction and 150,000-hour L70 lifespan ensure reliable performance with minimal maintenance.
Key Features & Benefits
- Energy Efficient: 10W LED consumes less power, replacing traditional 60W-75W bulbs. Saves on energy costs.
- High-Quality Light: 900 lumens at 5000K (Daylight) for bright, clear visibility and enhanced security.
- Extremely Long Life: 150,000-hour rated lifespan (L70) drastically reduces replacement frequency and maintenance costs.
- Robust & Durable Construction: Die-cast aluminum housing with gray powder-coat finish resists corrosion.
- Universal Voltage & Wet Location Rated: 120-277V input for versatile installation. cETLus listed for use in wet locations (UL1598).
- Commercial & Industrial Ready: High Power Factor (≥0.90), low THD (<20%), and wide operating temperature range (-40°C to +40°C).
- 5-Year Warranty: Backed by SYLVANIA for peace of mind.
Detailed Specifications
| Specification | Detail |
|---|---|
| Wattage | 10W |
| Light Output (Lumens) | 900 lm |
| Efficacy | 90 lm/W |
| Color Temperature | 4000K (Cool White) |
| CRI (Color Rendering Index) | 70 |
| Input Voltage | 120–277V AC (Universal) |
| Power Factor | ≥ 0.90 |
| Total Harmonic Distortion (THD) | < 20% |
| Rated Lifespan (L70) | 150,000 hours |
| Housing Material & Finish | Die-Cast Aluminum, Gray Powder-Coated |
| Lens Material | Frosted Glass |
| Mounting Type | Surface Ceiling Mount |
| Dimensions (Diameter x Height) | 4.6 in x 7.6 in (116.84 mm x 193.04 mm) |
| Weight | 5.7 lbs (2.6 kg) |
| Operating Temperature | -40°C to +40°C (-40°F to 104°F) |
| Certifications & Listings | cETLus (UL1598 Wet Location), RoHS, FCC, FTC |
| Model / Product Number | 60168 |
| UPC Code | 046135601675 |
Ideal Applications
- Commercial and Industrial Building Exteriors & Entrances
- Parking Garages, Walkways, and Covered Corridors
- Warehouses, Storage Areas, and Utility Rooms
- Stairwells, Hallways, and Loading Docks
- Any Wet or Damp Location Requiring Durable Ceiling Lighting
What’s Included in the Box
- 1 x SYLVANIA Jelly Jar LED Light Fixture
- Necessary Mounting Hardware
- Product Documentation and Warranty Information
Helpful Installation & Usage Tips
- This fixture is designed for direct surface ceiling mounting. A junction box is required but not included.
- Ideal for replacing old incandescent, CFL, or fluorescent jelly jar/vapor-tight fixtures.
- Can be used with compatible hanging pendant kits or wall mount brackets (sold separately) for added flexibility.
- Ensure power is turned off at the circuit breaker before installation.
