Osram 11558 EBV 118V Photo Incandescent Lamp - 120W Med 17800lm

Osram 11519/1158 EBV — 500W 118V Super Photoflood Incandescent Lamp, 3400K, E26 Medium Base

The Osram 11519 EBV is a 500-watt, 118-volt tungsten incandescent super photoflood lamp from Osram, designed for studio, TV, film, stage, theatre, and professional photography applications. With an E26 medium brass base, PS25 bulb shape, 17,500 lumens, 3400K color temperature, CRI 100, and an 8-hour rated life, this lamp delivers high-intensity, tungsten-balanced illumination for professional optical and lighting equipment. Dimmable with traditional amber shift. Sold in cases of 24 (1 per sleeve). Verify ANSI code, wattage, voltage, base, and bulb shape against your existing lamp or equipment manual before ordering.

Technical Specifications

Product Overview

The Osram 11519 EBV is a professional tungsten incandescent super photoflood lamp engineered for studio, TV, film, stage, theatre, and professional photography applications. At 3400K with CRI 100 and 17,500 initial lumens, it delivers high-intensity, stable tungsten-balanced output suited for photographic, broadcast, and production lighting environments where accurate, consistent color temperature is critical.

The 3400K color temperature is slightly warmer than the 3200K standard tungsten balance — EBV lamps are specifically designed for photoflood applications where 3400K is the expected color temperature for photographic film and camera white balance settings. The 8-hour rated life is standard for a high-output 500W photoflood at this voltage. Instant-on operation with no warm-up delay. Dimmable with traditional amber shift.

Compatible Applications

• Studio, TV, and film lighting — 3400K tungsten-balanced output for camera-accurate production and photographic lighting.
• Stage and theatre lighting — Super photoflood for theatrical fixtures requiring EBV-designated lamps.
• Professional photography — High-output photoflood for studio strobe and continuous light equipment where EBV is specified.
• Projectors and optical equipment — Where EBV-designated lamps are specified by equipment manufacturer.

Before Ordering — Verify

• ANSI Code / Ordering Abbreviation: Confirm the existing lamp or equipment manual specifies EBV or EBV 500W 118V.
• Voltage: Confirm equipment is rated for 118V nominal / 120V. Operating above rated voltage shortens lamp life.
• Wattage: Confirm the fixture or instrument is rated for 500W.
• Base Type: Confirm the socket accepts an E26 Medium Brass base.
• Bulb Shape: Confirm the PS25 shape and 176.2mm length fit within the equipment's lamp housing with adequate clearance.

Safety and Installation Guidelines

• Approved Fixtures Only: Install only in equipment designed for this lamp type, wattage, voltage, and base.
• Disconnect Power: Turn off and unplug equipment before replacing the lamp.
• Allow Cooling: Let the lamp and fixture cool completely before handling — this lamp operates at very high surface temperatures.
• Optical Alignment: Seat the lamp correctly to maintain proper focus, beam position, and equipment performance.
• Handle with Care: Inspect the bulb for cracks or damage before installation. Do not use a damaged lamp.

Compliance

• Mercury-free.
• Verify RoHS compliance status and Prop 65 requirements with the Osram manufacturer specification sheet prior to use in regulated installations.

Ordering Information

• Brand: Osram
• Osram Product Number: 11519 or 11558
• ANSI Code: EBV
• UPC / EAN: 4052899468016
• Wattage / Voltage: 500W / 118V
• Base: E26 Medium Brass
• Packaging: Sold in cases of 24 (1 per sleeve).
• Case quantities and bulk pricing: Contact ADL Supply for volume orders.

For wholesale pricing, bulk availability, or help confirming the correct replacement lamp, contact ADL Supply at 1-800-235-3489.
