Osram 54696 DTY Photo-Optic Halogen Lamp - 3200W 10000 120V G38
The Osram 54696 DTY Photo-Optic Halogen Lamp - 3200W 10000 120V G38 is an OSRAM specialty photo-optic halogen lamp used in professional projection, microfilm, microscope, studio, medical, fiber-optic, and entertainment equipment. This lamp should be selected by matching the ordering abbreviation, wattage, voltage, base, bulb shape, and rated life to the existing lamp or equipment manual.
This product is listed with 3200W, 10000 120V, G38 base, T24 bulb shape, 290500 lumens, and 350 hour rated average life. It is intended for specialized optical systems where correct fit and light output are critical.
Wattage 3200W Halogen | Voltage 10000 120V Rated | Base G38 Socket | Lumens 290500 Output | Life 350 hrs Avg. |
Product Overview
OSRAM photo-optic halogen lamps are designed for equipment where optical alignment, color stability, and lamp geometry matter. These lamps are commonly used in projectors, microfilm readers, microscopes, studio fixtures, medical illumination, fiber-optic illuminators, enlargers, printers, and entertainment lighting.
Technical Specifications
| Brand | OSRAM |
| Product Number | 54696 |
| ANSI / Code | DTY |
| Ordering Abbreviation | DTY |
| Primary Application | Studio, Theatre, TV & Video |
| Wattage | 3200W |
| Voltage | 10000 120V |
| Base Type | G38 |
| Bulb Shape | T24 |
| Lumens | 290500 |
| Color Temperature | Not Listed |
| Rated Average Life | 350 hours |
| Package Quantity | 1 |
| Mercury Content | Mercury-free tungsten halogen lamp |
Compatible Applications
- Projectors and slide projection systems
- Microfilm and microfiche readers
- Microscopes and laboratory illuminators
- Studio, theatre, TV, and video lighting equipment
- Medical and dental illumination systems where specified
- Fiber-optic illuminators and optical equipment
Helpful Buying Notes
- Replacement Accuracy: Match the ordering abbreviation, wattage, voltage, base, and bulb shape before ordering.
Before Ordering Verify
- Ordering Code: Match OSRAM 54696 / DTY to the existing lamp or equipment manual.
- Voltage: Confirm the equipment is rated for 10000 120V operation.
- Wattage: Confirm the fixture or instrument is rated for 3200W.
- Base: Confirm the socket accepts G38 lamps.
- Bulb Shape: Confirm the T24 bulb shape and physical clearance.
- Life vs Output: Long-life versions may produce fewer lumens, while high-output versions may have shorter life.
Safety & Installation Guidelines
- Use Approved Fixtures: Install only in equipment designed for this lamp type, wattage, voltage, and base.
- Do Not Touch Quartz: Use clean gloves or a lint-free cloth to prevent oil contamination and premature lamp failure.
- Disconnect Power: Turn off and unplug equipment before replacing the lamp.
- Allow Cooling: Let the lamp and fixture cool completely before handling.
- Optical Alignment: Seat the lamp correctly to maintain proper focus, beam position, and equipment performance.
Wholesale & Project Support
ADL Supply supports schools, labs, AV departments, medical facilities, maintenance teams, and commercial buyers with OSRAM photo-optic lamp sourcing, replacement identification, and volume order support.
For volume pricing, availability, or help confirming the correct OSRAM replacement lamp, contact ADL Supply at 1-800-235-3489.
