Product Overview
Satco S28483 11.5A19LED/940/120V — 11.5W LED A19 Bulb, 4000K, 90 CRI, 75W Equivalent, E26 Medium Base, Dimmable, CEC/Title 20 Compliant
The Satco S28483 (11.5A19LED/940/120V) is an 11.5-watt LED A19 bulb from Satco/Nuvo, designed as a direct, dimmable replacement for a 75W incandescent A19 bulb on a standard E26 medium base. With a frosted finish, 4000K color temperature (Cool White), CRI 90+, 1,100 lumens, a 220° beam angle, and a 25,000-hour rated life, this lamp is cULus Listed, damp location rated, and approved for use in totally enclosed fixtures. Dimmable on 120V circuits with phase-cut (Triac-type) dimmers. California Title 20 and Title 24/JA8 compliant — approved for California sale. Sold 6 per inner pack, 24 per case. Verify dimmer compatibility before ordering.
| Wattage 11.5W Replaces 75W | Lumens 1,100 lm ~96 LPW | Color Temp 4000K Cool White | Base E26 Medium A19 Frosted | Dimming Dimmable |
Technical Specifications
| Brand | Satco / Nuvo |
| Item Number | S28483 |
| Order Code | 11.5A19LED/940/120V |
| Bulb Type | A19 |
| Lamp Type Classification | Type A |
| Base Type | Medium (E26) |
| Finish | Frost |
| Housing Color | White |
| Input Voltage | 120V |
| Wattage | 11.5W |
| Incandescent Equivalent | 75W |
| Current Draw | 0.096A |
| Operating Frequency | 60Hz |
| Initial Lumens | 1,100 lm |
| Color Temperature | 4000K (Cool White) |
| CRI | 90+ |
| Beam Angle | 220° (Omnidirectional) |
| Power Factor | 0.96 |
| Dimming Type | Yes — 120V only, phase-cut (Triac-type) dimmers |
| Rated Life | 25,000 hours |
| Operating Temperature | -25°C to +45°C (-13°F to +113°F) |
| Maximum Overall Length (MOL) | 4.33" |
| Maximum Outer Diameter (MOD) | 2.36" |
| Operating Position | Universal |
| Fixture Rating | Enclosed Fixture Rated |
| Location Rating | Damp |
| Safety Listing | cULus Certified, cULus Listed |
| FCC Compliant | Yes |
| RoHS Compliant | Yes |
| DLC Approved | No |
| California Title 20 | Yes |
| California Title 24 / JA8 | Yes — California Title 24 Listed |
| Inner Pack Quantity | 6 |
| Case Quantity | 24 |
| UPC | 045923284830 |
| Warranty | 5-year limited warranty |
Notes: I don't have an individual spec sheet for this exact E26-base SKU. These values are carried over from the closely related GU24-base siblings in this same wattage/CRI/CEC-T20 tier (items S21324, S21325, S28485), which I do have individual sheets for — same engine and electrical specs, different base type. Two corrections applied consistent with that family: Location Rating set to Damp (the prior listing said Wet Location Rated). Base type, MOL, and ANSI base reflect the E26 medium base specific to this SKU rather than GU24.
Product Overview
The Satco S28483 is an 11.5W LED A19 bulb on a standard E26 medium base, with a frosted plastic lens and a high CRI of 90+ for accurate color rendering. It delivers 1,100 lumens at 4000K (Cool White) with a wide 220° beam angle.
This lamp is dimmable on 120V circuits using phase-cut (Triac-type) dimmers, and is rated for damp locations and totally enclosed fixtures. It is cULus Listed and carries a 5-year limited warranty.
This SKU is part of Satco’s 90 CRI, CEC/Title 20-compliant A19 line, and is California Title 24 Listed — approved for sale in California energy-code-regulated projects, on a standard medium base for fixtures that don’t require GU24.
Compatible Applications
- Indoor residential and commercial lighting — General-purpose E26 fixtures.
- Totally enclosed fixtures — Approved for use where airflow is restricted.
- California Title 20/24-regulated projects — New construction and renovation requiring compliant, high-CRI lamps.
- Damp locations — Covered outdoor fixtures and humid indoor spaces (not for direct wet exposure).
Before Ordering — Verify
- Dimmer Compatibility: Compatible with 120V phase-cut (Triac-type) dimmers only.
- Color Temperature: Confirm 4000K is correct — the E26 CEC/Title 20 family in this wattage class also includes 2700K (item S28650, not in this batch). A GU24-base version of this same tier is also available (items S21324/S21325/S28485) for fixtures requiring that base.
- Fixture Rating: Damp location rated — not for direct wet/outdoor exposure despite being enclosed-fixture approved.
- Voltage: Confirm the application is 120V.
Safety and Handling Guidelines
- Disconnect power before installing or replacing this lamp.
- Dimmer Use: Use only with compatible 120V phase-cut dimmers; incompatible dimmers may cause flicker or premature failure.
- Environment: Damp location rated only — do not install where it will be directly exposed to rain or water.
- Fixture Type: Safe for use in totally enclosed fixtures.
- Code Compliance: Install and operate in accordance with the National Electrical Code (NEC) and all applicable local codes.
Compliance
- cULus Certified and cULus Listed, FCC compliant, RoHS compliant.
- Damp location rated; approved for totally enclosed fixtures.
- California Title 20 compliant and California Title 24/JA8 Listed — approved for sale and shipment to California.
- Not DLC approved.
- Mercury-free, lead-free LED lamp — no mercury-related shipping restrictions apply.
- 5-year limited warranty.
Ordering Information
- Brand: Satco / Nuvo
- Item Number: S28483
- Order Code: 11.5A19LED/940/120V
- UPC: 045923284830
- Wattage / CCT: 11.5W / 4000K
- Base: E26 Medium (A19 Frosted)
- Equivalent: 75W Incandescent
- Packaging: 6 per inner pack, 24 per case.
- Case quantities and bulk pricing: Contact ADL Supply for volume orders.
For wholesale pricing, bulk availability, or help confirming the correct replacement lamp, contact ADL Supply at 1-800-235-3489.
