Satco S28485 — 11.5W LED A19, GU24, 4000K, 90 CRI, Dimmable, CEC/Title 20

Satco S28485 11.5A19LED/940/GU24/120V — 11.5W LED A19 Bulb, GU24 Base, 4000K, 90 CRI, 75W Equivalent, Dimmable, CEC/Title 20 Compliant

The Satco S28485 (11.5A19LED/940/GU24/120V) is an 11.5-watt LED A19 bulb from Satco/Nuvo, designed as a direct, dimmable replacement for a 75W incandescent A19 bulb on a GU24 base. With a frosted finish, 4000K color temperature (Cool White), CRI 90+, 1,100 lumens, a 220° beam angle, and a 25,000-hour rated life, this lamp is cULus Listed, damp location rated, and approved for use in totally enclosed fixtures. Dimmable on 120V circuits with phase-cut (Triac-type) dimmers only. California Title 20 and Title 24/JA8 compliant (California Title 24 Listed) — approved for California sale. GU24 base is not interchangeable with standard E26 medium-base sockets. Sold 6 per inner pack, 24 per case. Verify dimmer compatibility and base type before ordering.

Technical Specifications

Minor note: this item's spec sheet lists “Style: Traditional,” while the 2700K and 3000K siblings (S21324, S21325) list “Style: Transitional” despite being otherwise spec-identical. Likely just an inconsistency in Satco's own internal data rather than a real design difference; not reflected as a meaningful spec above.

Product Overview

The Satco S28485 is an 11.5W LED A19 bulb on a GU24 twist-lock base, with a frosted plastic lens and a high CRI of 90+ for accurate color rendering. It delivers 1,100 lumens at 4000K (Cool White) with a wide 220° beam angle for broad, even light distribution.

This lamp is dimmable on 120V circuits using phase-cut (Triac-type) dimmers, and is rated for damp locations and totally enclosed fixtures. It is cULus Listed and carries a 5-year limited warranty.

This SKU is part of Satco’s 90 CRI, CEC/Title 20-compliant A19 line, and is explicitly California Title 24 Listed — approved for sale in California energy-code-regulated projects. The GU24 base’s twist-lock design prevents standard screw-base (E26) bulbs from being installed in fixtures designed for high-efficacy-only lamps, a common requirement in California new construction and renovation.

Compatible Applications

• Indoor residential and commercial lighting — General-purpose GU24 fixtures.
• Totally enclosed fixtures — Approved for use where airflow is restricted.
• California Title 20/24-regulated projects — New construction and renovation requiring compliant, high-efficacy GU24 lamps.
• Damp locations — Covered outdoor fixtures and humid indoor spaces (not for direct wet exposure).

Before Ordering — Verify

• Base Type: This is a GU24 twist-lock base, not a standard E26 medium screw base — confirm the fixture has a GU24 socket before ordering.
• Dimmer Compatibility: Compatible with 120V phase-cut (Triac-type) dimmers only — confirm dimmer type before specifying for a dimmed application.
• Color Temperature: Confirm 4000K is correct — this 90 CRI/CEC-T20 GU24 family also includes: S21324 (2700K), S21325 (3000K), S28485 (4000K).
• CRI / Compliance Tier: This is the 90 CRI, CEC/Title 20-compliant tier. Satco also offers a lower-cost, non-T20, 80 CRI GU24 version in this same wattage class (items S29814 at 2700K and S29804 at 4000K) for projects that don't require CA compliance — confirm which tier the project needs.
• Fixture Rating: Damp location rated — not for direct wet/outdoor exposure despite being enclosed-fixture approved.
• Voltage: Confirm the application is 120V.

Safety and Handling Guidelines

• Disconnect power before installing or replacing this lamp.
• Base Type: Confirm GU24 socket compatibility before installation — this base does not fit standard medium (E26) sockets.
• Dimmer Use: Use only with compatible 120V phase-cut dimmers; incompatible dimmers may cause flicker or premature failure.
• Environment: Damp location rated only — do not install where it will be directly exposed to rain or water.
• Fixture Type: Safe for use in totally enclosed fixtures.
• Code Compliance: Install and operate in accordance with the National Electrical Code (NEC) and all applicable local codes.

Compliance

• cULus Certified and cULus Listed, FCC compliant, RoHS compliant.
• Damp location rated; approved for totally enclosed fixtures.
• California Title 20 compliant and California Title 24/JA8 Listed — approved for sale and shipment to California.
• Not DLC approved.
• Mercury-free, lead-free LED lamp — no mercury-related shipping restrictions apply.
• 5-year limited warranty.

Ordering Information

• Brand: Satco / Nuvo
• Item Number: S28485
• Order Code: 11.5A19LED/940/GU24/120V
• UPC: 045923284854
• Wattage / CCT: 11.5W / 4000K
• Base: GU24 (A19 Frosted)
• Equivalent: 75W Incandescent
• Packaging: 6 per inner pack, 24 per case.
• Case quantities and bulk pricing: Contact ADL Supply for volume orders.

For wholesale pricing, bulk availability, or help confirming the correct replacement lamp, contact ADL Supply at 1-800-235-3489.
