Sollos P90-AB-20-JC3/830/IP65/LED 27536S 90° Right Angle Path Light 20" Stem Antique Brass

Sollos P90-AB-20 (27536S) 90° Right Angle Path Light – 20" Stem, Antique Brass

The Sollos P90-AB-20 (product number 27536S) is a 12V AC low-voltage, right-angle "P90°" path light with a die-cast aluminum head and a 20" stem, finished in Antique Brass. The fixture uses a clear polycarbonate lens, a stepped threaded collar for tool-less relamping, and a ceramic G4 bi-pin socket rated for lamps up to 20 watts. It ships with a 36" 18-2 lead wire, two King® DryConn™ waterproof connectors, and an 8" ground stake. This is a kitted assembly supplied with a Halco ProLED JC3/830/OMNI/IP65/LED G4 bi-pin LED lamp installed (3000K, IP65-rated, 20W-equivalent). Confirm finish, lamp inclusion, and transformer capacity before ordering.

Technical Specifications

Product Overview

The Sollos P90° is a right-angle path light: a 20" straight stem terminating in a die-cast aluminum head bent at 90 degrees, aiming the lamp downward onto walkways and garden edging rather than through a mushroom-style hat. The design keeps the light source shielded from direct view while throwing a tight, low pool of light along the ground – well suited to narrow paths and formal edging where a wide hat silhouette is not wanted.

The housing is finished in Antique Brass UV- and corrosion-resistant powder coat. The collar is stepped and threaded so the head can be opened by hand for relamping without tools, and a clear threaded polycarbonate lens protects the lamp. The ceramic G4 bi-pin socket accepts JC bi-pin lamps up to 20 watts.

This order code is supplied as a kitted assembly with a Halco ProLED JC3/830/OMNI/IP65/LED lamp included (2.5W, 20W-equivalent, 3000K, CRI 80, 300 lumens, 15,000 hours rated useful life). The lamp is IP65-rated for direct exposure to rain or irrigation and is built for omnidirectional, even light distribution. It is not compatible with dimmers, timers, photo sensors, or occupancy sensor controls. The fixture-only version of the same finish is sold under a separate order code. Every fixture ships with a 36" 18-2 lead wire, two King DryConn waterproof connectors, and an 8" ground stake, and operates on a 12V AC landscape transformer ordered separately.

Compatible Applications

• Narrow walkway and garden edging illumination
• Driveway and paver-edge lighting where a low, discreet fixture profile is preferred
• Residential and commercial landscape lighting on a 12V AC circuit
• Formal garden beds, hardscape borders, and entry paths
• Retrofit replacement for existing right-angle 12V path fixtures

Before Ordering – Verify

• This is a 12V AC low-voltage fixture. It will be destroyed if connected to 120V line voltage. A 12V landscape transformer is required and is not included.
• Socket is G4 bi-pin, not GU5.3 MR16 and not GU10. MR16 and GU10 lamps will not fit this fixture.
• This order code includes an LED lamp. If you need the fixture without a lamp, order the fixture-only version of the same finish instead.
• The included lamp is not compatible with dimmers, timing devices, photo sensors, or occupancy sensors. Do not specify this kit for a controlled circuit.
• Confirm finish: this item is Antique Brass. Also offered in P90-TB-20-JC3/830/IP65/LED, P90-TZ-20-JC3/830/IP65/LED.
• Antique Brass carries a lifetime warranty; Textured Black and Textured Bronze carry a 5-year warranty – confirm which finish before ordering if warranty terms matter to the buyer.
• Total the wattage of every fixture on the run and size the transformer accordingly, allowing headroom for future additions.
• ProLED lamps may not be compatible with every dimming system; test on the actual circuit before completing a full installation.

Safety and Handling Guidelines

• De-energize the transformer before wiring, relamping, or servicing the fixture.
• Make all splices with the supplied King DryConn waterproof connectors and keep connections out of standing water.
• Bury or otherwise protect the low-voltage cable run to prevent damage from mowers, edgers, and digging.
• Do not exceed the 20W maximum lamp rating. Overlamping causes excess heat, socket damage, and lens degradation.
• Drive the ground stake into soil only; do not hammer on the fixture housing or stem.
• Keep the lens clear of mulch, soil, and dense foliage so heat can dissipate.
• This fixture contains no mercury; the LED kit lamp is mercury-free.
• Do not connect the included lamp to a dimmer, timer, photo sensor, or occupancy sensor – the lamp is not rated for these controls and may fail prematurely.

Compliance

• ETL Listed to UL 1838 (Low Voltage Landscape Lighting Systems) and CSA C22.2 No. 250.7.
• Intended for use on Class 2 / low-voltage landscape lighting circuits supplied by a listed 12V landscape transformer.
• Install in accordance with the National Electrical Code and all applicable local codes; NEC Article 411 governs low-voltage lighting systems.
• Kitted lamp (Halco JC3/830/OMNI/IP65/LED) is IP65-rated for direct exposure to rain or irrigation spray and is RoHS compliant; the fixture-only version carries no published IP rating for the fixture body – pair with an IP65 ProLED lamp for wet-exposed installs.
• Lamp warranty: 2-year Commercial/Industrial limited warranty from date of purchase (Halco), separate from the fixture warranty above.
• Mercury-free product. RoHS-compliant construction.
• All specifications are subject to change by the manufacturer; the current Sollos published specification governs.

Ordering Information

• Order code: P90-AB-20-JC3/830/IP65/LED  |  Sollos product number: 27536S  |  ADL Supply SKU: SOLL27536S
• Configuration: 90° right-angle path light, 20" stem, Antique Brass, 12V AC, G4 bi-pin, 20W max.
• Supplied with a Halco ProLED JC3/830/OMNI/IP65/LED lamp (Halco 81996) installed, 2.5W, 3000K, 300 lumens, CRI 80, 15,000 hours useful life.
• Included with every fixture: 8" ground stake, 36" 18-2 lead wire, two King DryConn waterproof connectors.
• Manufacturer-matched kit lamp: Halco JC3/830/OMNI/IP65/LED (Halco 81996), 2.5W / 20W-equivalent, 3000K, 10-15V input, IP65, 15,000 hours life. Also available in this series: JC1/830/OMNI/IP65/LED (81998, 1.2W, 110 lm) and JC2/830/OMNI/IP65/LED (81999, 2.0W, 200 lm).
• Also available: P90-TB-20-JC3/830/IP65/LED, P90-TZ-20-JC3/830/IP65/LED, and the fixture-only equivalent of this finish.
• Related Sollos new-arrival families: PBL Bollard Path Light (16" stem) and PTH075 Adjustable Base Path Light.
• Warranty: Lifetime limited warranty on Antique Brass finish.

For wholesale pricing, bulk availability, or help confirming the correct replacement lamp, contact ADL Supply at 1-800-235-3489.
