GE 22686 QH1600T3/CL

Product Overview

GE 22686 QH1600T3/CL — 1600W 210V T3 Tubular Quartz Halogen Infrared Heat Lamp, Horizontal Burn

The GE 22686 QH1600T3/CL is a 1600-watt, 210-volt T3 tubular quartz halogen infrared heat lamp from GE Lighting, designed for industrial and commercial high-temperature infrared heating applications. With a C-8 filament, 2350K color temperature, 19.80" MOL, 0.375" (T3) diameter, r7s recessed single contact base (each end), horizontal burn position, and a rated life of 5,000 hours, this lamp delivers reliable radiant infrared output for process heating, drying, curing, and warming applications. Verify voltage, wattage, burn position, and physical dimensions before ordering.

Wattage

1600W

T3 Quartz

Voltage

210V

Rated

Color Temp

2350K

Infrared / Heat

Burn Position

Horizontal

Verify Before Use

Rated Life

5,000 hrs

Average Life

Technical Specifications

Brand	GE Lighting
GE Order Code	22686
Description	QH1600T3/CL
Lamp Type	T3 Tubular Quartz Halogen Infrared
Wattage	1600W
Voltage	210V
Color Temperature	2350K
Filament	C-8
Burn / Operating Position	Horizontal
Rated Average Life	5,000 hours
Max Overall Length (MOL)	19.80"
Diameter	0.375" (T3)
Termination	R7s recessed single contact base (each end)
UPC / EAN	043168226868

Product Overview

The GE 22686 QH1600T3/CL is a tubular quartz halogen infrared lamp engineered for industrial process heating, drying, curing, and warming applications. At 1600W and 210V, this lamp delivers radiant infrared energy output from a compact T3 quartz envelope (19.80" long), making it suitable for installation in industrial heating fixtures and equipment designed for this exact wattage and voltage.

The 2350K color temperature reflects operation at a filament temperature calibrated for infrared process heat rather than general illumination — producing a high proportion of infrared radiation relative to visible light. The R7s recessed single contact base (each end) provides a connection suited to industrial fixture mounting. Horizontal burn position only — operating at other orientations will cause premature filament sag and failure.

Compatible Applications

Industrial process heating — Drying, curing, baking, and thermal processing equipment requiring 1600W 210V tubular quartz infrared sources.
Commercial warming and heating equipment — Food service warming equipment, outdoor patio heaters, and comfort heating fixtures using T3 quartz halogen elements.
Retrofit and maintenance replacement — Confirm voltage, wattage, MOL, diameter, burn position, and termination style before ordering.

Before Ordering — Verify

Voltage: Confirm equipment is rated for 210V. Do not install on a mismatched voltage system.
Wattage: Confirm the fixture or equipment is rated for 1600W.
Burn Position: This lamp is rated for horizontal operation only. Vertical or angled installation will cause premature filament failure.
Physical Dimensions: Confirm 19.80" MOL and 0.375" (T3) diameter fit within your fixture or equipment lamp housing.
Termination: Confirm your fixture accommodates r7s recessed single contact base (each end).

Safety and Handling Guidelines

Extreme Heat Warning: This lamp operates at very high surface temperatures. Use only in approved fixtures or equipment rated for high-temperature quartz halogen infrared operation. Keep all combustible materials away from the lamp and fixture.
Do not touch the quartz envelope with bare hands. Skin oils cause hot spots leading to premature failure. Use clean gloves or a lint-free cloth. If accidentally touched, clean with isopropyl alcohol before use.
Horizontal Burn Position Only: Operating vertically or at an angle will cause premature filament sag and lamp failure.
Do not exceed rated voltage. Operating above 210V dramatically shortens lamp life.
Allow Complete Cool-Down: Allow the lamp to cool fully before handling or replacement.
Disconnect Power: De-energize the circuit before lamp replacement. 210V systems carry lethal voltage.
