Product Overview
Philips 31488-0 EFP – 100W / 12V Photo Projection Lamp, GZ6.35 Base
The Philips 31488-0 (EFP) is a 100-watt, 12-volt photo projection / instrument lamp with a GZ6.35 base and MR16 bulb, rated for a 50-hour average life at 3350K color temperature in the BDTH burning position. This lamp is stocked by ADL Supply for AV, projection, and instrument-lighting replacement programs.
WATTAGE 100W Photo Projection Lamp | VOLTAGE 12V Rated voltage | RATED LIFE 50 hrs Average life | BASE GZ6.35 MR16 bulb | CCT 3350K Color temperature |
Technical Specifications
| Manufacturer | Philips (Signify) |
| Product Line | Photo Projection Lamps |
| ANSI / Type Code | EFP |
| Product Number | 31488-0 |
| Wattage | 100W |
| Voltage | 12V |
| Bulb Shape | MR16 |
| Base | GZ6.35 |
| Packaging Quantity | 50 per case |
| Rated Average Life | 50 hours |
| Coil / Filament Type | C-6 |
| MOL (Maximum Overall Length) | 42.0 mm |
| Rated Approx. Lumens | Not published |
| Color Temperature | 3350K |
| Operating / Burning Position | BDTH |
Product Overview
The 31488-0 (EFP) is a low-voltage halogen lamp from Philips' Photo Projection Lamps line, built for precise, repeatable output in projection, photographic, and instrument applications. It is rated for bdth burning position and a 50-hour average life at 12V.
Photo projection lamps are precision-manufactured to tight filament and envelope tolerances so that beam pattern and color are consistent from lamp to lamp; always confirm the ANSI/type code and voltage against your equipment's original lamp specification before ordering, as many lamps in this family share similar bases and wattages across different voltages.
Compatible Applications
- Slide, movie, and overhead projectors
- Microscope and instrument illumination
- Photographic and audiovisual equipment
- Medical, dental, and scientific instrument lighting
- Retrofit replacement in fixtures originally specified for this ANSI/type code
Before Ordering – Verify
- Confirm the ANSI/type code (EFP) and voltage (12V) against your equipment's original lamp specification — this lamp family includes many similar-looking lamps that share a base and wattage but differ in voltage.
- Confirm base type (GZ6.35) and bulb shape (MR16) match your equipment's lamp socket/reflector.
- Confirm burning position (BDTH) is compatible with your fixture's mounting orientation.
Safety and Handling Guidelines
- Turn power off before inspection, installation, or removal of the lamp.
- Allow the lamp to cool completely before handling or relamping — these lamps operate at high filament and envelope temperature.
- Do not touch the bulb envelope with bare hands; oils can cause premature failure and hot spots. Handle by the base wherever possible.
- Do not use the lamp if the outer glass is scratched or broken.
- Do not exceed rated voltage; overvoltaging shortens life and increases the risk of premature failure.
Compliance
- Dispose of/recycle according to federal, state, and local regulations for lamp components.
- Confirm ANSI/type code EFP matches your equipment documentation before installation.
Ordering Information
- ANSI / Type Code: EFP
- Product Number: 31488-0
- Packaging: 50 per case
- Contact ADL Supply for current wholesale pricing and stock availability.
For wholesale pricing, bulk availability, or help confirming the correct replacement lamp, contact ADL Supply at 1-800-235-3489.
