Product Overview
Ushio 1000915 JCD24V-60W – 60W 24V Halogen Lamp
The Ushio 1000915 JCD24V-60W is a 60-watt, 24-volt halogen lamp with a Double Contact Bayonet Base (BA15d). Ushio lists it with a 500-hour average life, rated at 1,260 lumens.
This lamp is listed under Ushio description JCD24V-60W.
| Wattage 60W Halogen | Voltage 24V Operating | Base BA15d Lamp Base | Lumens 1,260 Initial lm | Rated Life 500 Hrs Average Life |
Product Overview
The Ushio 1000915 is a JCD-series halogen lamp listed in the Halogen Low Voltage Bayonet section of the Ushio halogen catalog. Per Ushio, this lamp is for use only in approved enclosed halogen fixtures.
Always confirm the lamp code, wattage, voltage, base type, and burn position against your existing lamp or equipment manual before ordering.
Why Choose This Product
- 60W at 24V: Wattage and voltage as published by Ushio for catalog number 1000915.
- Published Output: 1,260 lumens per the Ushio catalog.
- 500-Hour Rated Life: Ushio’s published average life for this lamp.
- BA15d Base: Double Contact Bayonet Base (BA15d).
- Burn Position: Universal.
Technical Specifications
| Brand | Ushio |
| Ushio Catalog Number | 1000915 |
| Manufacturer Description | JCD24V-60W |
| Lamp Series | JCD |
| Catalog Category | Halogen Low Voltage Bayonet |
| Wattage | 60W |
| Operating Voltage | 24V |
| Initial Lumens | 1,260 |
| Rated Average Life | 500 Hours |
| Base Type | Double Contact Bayonet Base (BA15d) |
| Filament Type | CC-6 |
| Bulb Finish | Clear |
| Burn Position | Universal |
| Bulb Diameter (A) | 12.5 mm |
| Maximum Overall Length (MOL, B) | 60.5 mm |
| C-to-C (C) | 35.0 mm |
| Manufacturer Case Quantity | 100 |
Compatible Applications
- Fixtures and equipment specified for the JCD24V-60W lamp
- Maintenance replacement where voltage (24V), wattage (60W), base (BA15d), and burn position all match
- Approved enclosed halogen fixtures only, as required by Ushio
Cross Reference Numbers
- Ushio Catalog Number: 1000915
- Manufacturer Description: JCD24V-60W
- Common Search Terms: JCD24V-60W, 60W 24V halogen lamp
Before Ordering Verify
- Voltage: This lamp is rated for 24V operation. Do not install in fixtures requiring a different voltage.
- Wattage: Confirm your equipment is rated for a 60W lamp.
- Base Type: Confirm the socket matches the Double Contact Bayonet Base (BA15d).
- Burn Position: Ushio lists this lamp for universal operation; confirm it matches how your fixture holds the lamp.
- Dimensions: Ushio lists a maximum overall length of 60.5 mm and a bulb diameter of 12.5 mm; confirm they fit your fixture.
- Color Temperature: Ushio does not publish a color temperature for this catalog number. Contact ADL Supply if it is critical to your application.
Important Safety & Installation Notes
- Do Not Touch the Bulb With Bare Hands: Skin oils can create hot spots that may cause premature failure. Use clean gloves or a lint-free cloth.
- Use Approved Fixtures Only: Ushio specifies this lamp for use only in approved enclosed halogen fixtures. Install only in equipment designed for this lamp type, wattage, and voltage.
- Allow Cooling Before Replacement: Let the lamp and fixture cool before handling or replacing.
- Verify Voltage Before Installing: Operating above rated voltage can significantly shorten lamp life or cause lamp failure.
- Disconnect Power: Turn off and disconnect power before installing or removing the lamp.
