GE 67911 GE432MAX-GH UltraMax G-Series Ballast – 120-277V | 1.18 BF | 4-Lamp High Output T8

Premium high-performance electronic ballast designed for maximum light output and demanding commercial lighting environments.

Quick Specifications

• Model: GE432MAX-GH
• Part Number: 67911
• Series: UltraMax G-Series
• Input Voltage: 120–277V
• Lamp Configuration: 4 Lamp
• Ballast Factor: 1.18 (High Output)
• THD: <10%
• Minimum Starting Temperature: -20°F
• Maximum Case Temperature: 70°C
• Dimensions: 9.5" L x 1.3" W x 1.2" H
• Compliance: UL Type CC, FCC Part 18, RoHS, UL Type 1 Outdoor

Compatible Lamps

• (4) F32T8 (48" Standard Lamps)
• (4) Energy Saving T8 Lamps (25W, 28W, 30W)
• (4) F25T8 (36") and F17T8 (24")
• (3) F40T8 (specific wiring configuration)
• Equivalent U-Bend T8 Fluorescent Lamps

Product Overview

The GE432MAX-GH UltraMax G-Series ballast is a premium high-output electronic ballast engineered for demanding lighting applications where maximum performance is required.

With a 1.18 ballast factor, it delivers increased lumen output while maintaining high efficiency, making it ideal for large commercial and industrial environments.

Key Advantages

• Maximum brightness: ~15–20% higher light output
• Premium G-Series performance: Enhanced reliability and durability
• Multi-voltage flexibility: Works across 120–277V systems
• Parallel lamp operation: Maintains lighting if a lamp fails
• Cold start capability: Reliable down to -20°F

Applications

• Warehouses and distribution centers
• Retail environments requiring high illumination
• Commercial buildings with high ceilings
• Industrial facilities
• Large open-area lighting systems

Important Notes

• High Output Ballast: 1.18 BF delivers higher lumen output
• Higher energy consumption vs standard models
• Instant Start: Lower upfront cost, reduced lamp life vs programmed start
• Best suited for high brightness applications
