PHILIPS ADVANCE SMARTMATE ICF2S18H1LD | 1-2 Lamp 18W CFL | 120-277V

Philips Advance SmartMate ICF2S18H1LD is a highly versatile electronic ballast designed to power one or two 18-watt compact fluorescent lamps. Featuring IntelliVolt technology, this ballast operates on any input voltage from 120V to 277V, making it ideal for a wide range of commercial and institutional applications. The Programmed Start ignition method ensures optimal lamp life by precisely preheating the filaments, which is essential for environments using occupancy sensors. Its unique Dual-Entry design features color-coded poke-in terminals that support both side and bottom exit leads, providing maximum flexibility for various fixture mounting configurations.

Product Overview

The Philips Advance SmartMate ICF2S18H1LD is engineered for performance and convenience. Its high-frequency electronic design eliminates the hum and flicker often associated with older magnetic ballasts, earning a Class A sound rating for quiet operation. The inclusion of auto-restart circuitry means that after a lamp replacement, the ballast will automatically re-strike without the need to reset the power. This model also includes Lamp End-of-Life (EOL) protection, which safely removes power from the lamp if it detects a failure, preventing overheating and fixture damage. Note: This listing is for the individual ballast only and does not include a hardware kit.

• SmartMate Versatility: Dual-entry connectors allow for seamless use with either side-exit or bottom-exit wiring configurations.
• IntelliVolt Technology: Automatically senses and operates at any input voltage between 120V and 277V, 50/60Hz.
• Poke-In Terminals: Color-coded terminals simplify installation and ensure secure electrical connections.
• Energy Efficient: Reduces operating costs and is fully RoHS compliant for environmentally conscious projects.

Technical Specifications

• Brand: Philips Advance SmartMate
• Model Number: ICF-2S18-H1-LD (ICF2S18H1LD)
• Lamp Type: Compact Fluorescent (CFL) 4-Pin
• Number of Lamps: 1 or 2 Lamps
• Input Voltage: 120V-277V (50/60Hz)
• Start Method: Programmed Start
• Sound Rating: Class A
• Total Harmonic Distortion (THD): < 10%
• Safety Features: Lamp EOL Protection, Auto-Restart
• Certifications: UL Listed, CSA Certified, RoHS Compliant
• Assembly: Assembled in Mexico

Compatible Lamps

• 4-Pin Quad Tube (1-2 lamps): CFQ18W/G24q (PL-C18W/4P, F18BDX/4P, CF18DD/E)
• 4-Pin Triple Tube (1-2 lamps): CFTR18W/GX24q (PL-T18W, F18TBX/4P, CF18DT/E)
• 4-Pin 2D Lamps (1-2 lamps): CFS16W/GR10q (F162D), CFS21W/GR10q (F212D)

Cross Reference & Replacement

This ballast serves as a direct professional replacement for the following models:

• Universal: C218UNVME / C218UNVBE
• GE: GEC218-MVPS
• Sylvania: QTP1/2x18CF/UNV
• Robertson: PSM218CQMVW
• ESI: ES-2/1-CFQ-18/10-UNV-C
