Universal C13UNVME 2-Lamp 13W 120V-277V Programmed Rapid Start Electronic CFL Ballast

Multi-Ended Compact Fluorescent Ballast for Commercial Lighting

Compatible Lamp Types

• 1-2 lamps: CFQ13W/G24q (Philips PL-C13W/4P, GE F13BDX/4P, Sylvania CF13DD/E)
• 1-2 lamps: CFTR13W/GX24q (GE F13TBX/4P, Sylvania CF13DT/E)
• 1-2 lamps: CFS10W/GR10q (GE F102D/4P)
• 1-2 lamps: CFS16W/GR10q (GE F162D.4P)

Technical Specifications

Model:

C13UNVME

Wattage:

13W per lamp

Voltage Range:

108-305V AC, 50/60Hz

Mounting Type:

Multi-Ended (ME)

Start Method:

Programmed Rapid Start (PRS)

Power Factor:

>0.98

THD:

Low Distortion

Sound Rating:

Class A

Low Temp Start:

Down to 0°F (-18°C)

Product Features

• Universal voltage input (108-305V)
• 1 or 2 lamp operation flexibility
• End-of-lamp-life safety shutdown
• Auto-reset after shutdown (no power cycle needed)
• White casing eliminates ballast shadows
• Color-coded terminals for easy installation
• Cool operation extends product life
• Maximizes lamp life through PRS technology
