Product Overview
Osram 060860 Quicktronic Intelligent (1-10 V) 1X18-57 Dimming CFL Electronic Ballast
Operates the Following Lamps:
- 1 x DT/E 18W,1x DT/E 26W, 1x DT/E 32W,1 x DT/E 42W, 1 xDT/E 57
Additional Information:
- Osram EAN code: 4008321060860
- Supply Voltage 220-240V
- Line frequency 50…60 Hz
- Line voltage: 198 - 264V
- Digitally controlled preheating
- Same luminous flux with direct and alternating current
- The battery voltage may drop to 154 V. Ignition must take place above 198 V
- Digitally controlled preheating
Product benefits
Same luminous flux with direct and alternating current Perfect lamp start for applications with motion sensors Dimming of amalgam lamps without flickering or reduced lifespan Very high efficiency thanks to cut-off technology Automatic restart after lamp replacement ECGs comply with MINERGIE standard due to very low standby consumption Configurable emergency power characteristics Areas of application Suitable for use in emergency lighting systems as per EN 50172/DIN VDE 0108-100 Installation in emergency lighting systems according to IEC 61347-2-3, appendix J Industry Open-plan offices, corridors and storage rooms Public buildings Suitable for luminaires of protection class I Product features Control via 1…10 V interface Supply voltage: 220…240 V Line frequency: 0 Hz | 50 Hz | 60 Hz Line voltage: 198…264 V Dimming range: 3…100 % luminous flux Lamp start: within 0.6 s Lifetime: > 100,000 h (for T = 65 °C at Tc) Automatic shutdown of defective lamps and at end of life (EoL T.2) Energy Efficiency Index EEI: A1 BAT Overtemperature protection: Thermal management at high tc temperatures
