Sylvania Quicktronic 51415 QTP 4x32T8/UNV PSN-SC Programmed Start T8 Ballast – 120-277V | 0.88 BF Energy Saving | 3-4 Lamp | NEMA Premium

The Sylvania Quicktronic 51415 is a 3-or-4-lamp programmed start T8 electronic ballast with a 0.88 energy-saving ballast factor, delivering 30–60% energy reduction versus magnetic ballasts and 2–5W savings over standard electronic ballasts. With NEMA Premium certification, dual 120–277V voltage, parallel circuitry, lamp striation control, and remote mounting capability up to 20 feet, this ballast is the specification-grade choice for commercial energy efficiency programs, occupancy sensor installations, and utility rebate-qualifying projects.

Quick Specs

• Brand: Sylvania
• Model Number: 51415
• Product Code: QTP 4x32T8/UNV PSN-SC
• Series: Quicktronic
• Ballast Type: Electronic Fluorescent, Programmed Start
• Lamp Type: T8 Fluorescent
• Lamp Count: 3 or 4 Lamps
• Input Voltage: 120–277V Dual Voltage, 50/60Hz
• Ballast Factor: 0.88 (Energy Saving)
• Circuit Type: Parallel
• THD: <10%
• Sound Rating: Class A
• Temperature Range: -20°F (-29°C) to 70°C
• Remote Mounting: Up to 20 feet from lamps
• Energy Savings vs. Magnetic: 30–60%
• Energy Savings vs. Standard Electronic: 2–5W
• Lamp Striation Control: Yes
• Transient Protection: ANSI 62.41 Cat. A
• Dimensions (L x W x H): 9.47 in x 1.69 in x 1.18 in
• Certifications: UL Listed Class P, Type 1 Outdoor; CSA; FCC Part 18; UL935 Type CC; NEMA Premium
• PCB-Free: Yes

Product Overview

The Sylvania Quicktronic 51415 (QTP 4x32T8/UNV PSN-SC) is an energy-saving programmed start T8 ballast engineered for commercial lighting projects where operating cost reduction, utility rebate qualification, and occupancy sensor compatibility are primary specifications. The 0.88 ballast factor reduces lamp wattage draw below nominal rated output — delivering 2–5 watts of additional savings per ballast over standard 1.0-factor electronic ballasts, and 30–60% savings versus magnetic ballast systems. NEMA Premium certification validates the efficiency level required for most utility and energy efficiency rebate programs.

Programmed start technology preheats lamp cathodes before ignition — extending T8 lamp life in switching applications and making this ballast the correct specification for fixtures controlled by occupancy sensors, motion detectors, or daylight harvesting systems. Lamp striation control minimizes the visual banding effect that can appear in energy-saving T8 lamps, maintaining clean lamp appearance in open fixture designs where lamp aesthetics are visible.

Parallel circuit design keeps remaining lamps operating if one lamp fails. Remote mounting capability up to 20 feet supports ballast placement away from the lamp for temperature management or renovation layouts. ANSI 62.41 Cat. A transient protection safeguards the ballast from power line transients. UL Listed Class P, Type 1 Outdoor rating extends the application range to covered outdoor and damp location fixture installations.

Why Choose This Product

• 0.88 energy-saving ballast factor: Reduces lamp wattage draw 12% below nominal output — the correct specification when energy reduction is the project priority and full lumen output is not required.
• NEMA Premium certified — utility rebate eligible: Meets the efficiency standard required by most utility energy efficiency programs for rebate qualification on T8 ballast replacements.
• 30–60% energy savings over magnetic ballasts: Drop-in replacement for magnetic T8 systems with documented energy reduction across all standard T8 lamp types.
• Programmed start for occupancy sensor compatibility: Preheats cathodes before ignition — extends T8 lamp life in frequent-switching applications with occupancy sensors, motion detectors, or lighting control systems.
• Lamp striation control: Minimizes visual banding in energy-saving T8 lamps — important in open fixture designs where lamp appearance affects space aesthetics.
• Parallel circuit design: Remaining lamps stay lit when one lamp fails — reduces dark fixtures and maintenance urgency in large commercial installations.
• Remote mounting up to 20 feet: Allows ballast placement away from lamps for heat management, renovation constraints, or accessible service positioning.
• ANSI 62.41 Cat. A transient protection: Protects the ballast from power line voltage spikes — extends ballast service life in facilities with variable power quality.
• UL Class P, Type 1 Outdoor: Approved for outdoor and damp location applications when installed in appropriate enclosed fixtures.
• 100+ LPW efficacy with Octron 800 XP Supersaver lamps: Combined system delivers over 100 lumens per watt — qualifying for high-efficacy lighting specifications.

Technical Specifications

Dimensions

Lamp Compatibility

This ballast operates 3 or 4 lamps (3 lamps only for FO40 60-inch; 4 lamps only for FO30/SS) from the following compatible T8 fluorescent lamp types:

Note: FO30/SS Advantage operates on 4 lamps only. FO40 60-inch operates on 3 lamps only. Lampholders must be shorted per wiring diagram when operating fewer than the maximum lamp count.

Applications

The Sylvania Quicktronic 51415 is suited for commercial T8 fixture applications where energy savings, utility rebate eligibility, and occupancy sensor compatibility are required:

• Energy efficiency retrofit programs – NEMA Premium certification and 0.88 ballast factor meet utility rebate program requirements for T8 ballast replacements in commercial buildings.
• Occupancy sensor and lighting control installations – Programmed start technology extends T8 lamp life in frequently switched fixtures — the required specification when occupancy sensors or motion detectors control the circuit.
• Commercial offices and open-plan workspaces – 3-or-4-lamp troffer and strip fixture configurations with occupancy control and daylight harvesting in 120V or 277V distribution systems.
• Retail environments – Lamp striation control delivers clean, uniform lamp appearance in open troffer and strip fixtures on the sales floor.
• Schools and educational facilities – NEMA Premium efficiency and programmed start support energy codes and frequent-switching classroom lighting.
• Remote ballast mounting installations – 20-foot remote mounting capability supports ballast placement in accessible junction boxes or outside the luminaire housing.
• Cold-start and outdoor-adjacent applications – -20°F (-29°C) cold-start rating with UL Type 1 Outdoor listing supports covered outdoor and unheated space fixture installations.

Replacing Your Current T8 Ballast?

Confirm the following before ordering to ensure a compatible installation:

• Ballast factor — 0.88 energy-saving: This ballast operates lamps at 88% of rated output — producing 12% less light than a 1.0 ballast factor design. If your current ballast is 1.0 or 1.18, your fixture will produce less light after this replacement. Verify this tradeoff is acceptable before ordering.
• Lamp count — 3 or 4 lamps: FO30/SS Advantage is 4-lamp only; FO40 60-inch is 3-lamp only. This ballast is not rated for 1-or-2-lamp operation.
• Lampholder shorting requirement: Lampholders must be shorted per the included wiring diagram when operating fewer than the maximum lamp count. Failure to short lampholders correctly will cause the ballast to malfunction.
• Start method — programmed start: Correct for occupancy sensor and frequent-switching applications. Verify lamp compatibility with programmed start before ordering.
• Circuit voltage: Dual 120–277V covers all standard North American commercial voltages, 50/60Hz.
• Remote mounting: Maximum 20 feet of wire distance between ballast and lamps.
• Minimum starting temperature — SS lamps: FO30/SS Advantage lamps require a minimum starting temperature of 60°F (16°C). Do not use these lamps in environments that may fall below this threshold.
• Physical fit: 9.47 x 1.69 x 1.18 inches. Confirm your fixture ballast channel accommodates this footprint.

Installation Requirements

• Lampholder shorting: Lampholders must be shorted per wiring diagram included with the ballast.
• NEC compliance: Installation must comply with the National Electrical Code and all applicable local electrical codes.
• Minimum starting temperature with SS lamps: 60°F (16°C). Do not use FO30/SS Advantage lamps below this temperature.
• Case grounding: Ground the ballast case per the wiring diagram for safety compliance.
• Remote mounting: Maximum 20 feet of wire distance between ballast and lamps.

Ordering Information

• Brand: Sylvania
• Model Number: 51415
• Product Code: QTP 4x32T8/UNV PSN-SC
• Series: Quicktronic
• Lamp Type: 3–4 Lamp T8, Programmed Start, Energy Saving
• Voltage: 120–277V Dual Voltage
• Case quantities and bulk pricing: Contact ADL Supply for volume orders.

Compliance and Certifications

• UL Listed Class P, Type 1 Outdoor: Yes
• CSA Certified: Yes
• FCC Part 18 Compliant: Yes
• UL935 Type CC: Yes
• NEMA Premium Certified: Yes
• ANSI 62.41 Cat. A Transient Protection: Yes
• PCB-Free Construction: Yes
• Verify RoHS compliance status with manufacturer specification sheet.
• Verify California Title 20 / T24 compliance with manufacturer specification sheet.
• Verify Prop 65 warning requirements with manufacturer specification sheet.

ADL Supply recommends confirming all applicable compliance data with the Sylvania official product data sheet prior to specification or installation.
