GE 71497 UltraMax GE632MAXP-H90-S60

Product Overview

GE 71497 GE632MAX-H90-S60 UltraMax — 6-Lamp F40T8 Step-Dimming Electronic Ballast, 120V, High BF 1.18

The GE 71497 GE632MAX-H90-S60 UltraMax is a 6-lamp F40T8 electronic step-dimming instant start ballast from GE Lighting, designed for high-output commercial and industrial T8 fluorescent systems requiring bi-level switching capability. Bi-level step dimming switches between 100% and 60% light output. Ballast factor 1.18 (high output), 95% electrical efficiency, parallel lamp wiring, 120V input, 231W system watts, active power factor correction, anti-striation control, UL 55C high-temperature ambient rating, -20°F cold start, metal enclosure, remote mounting up to 6 feet. UL Type CC, UL Type 1 Outdoor, UL Type HL, cUL Listed, FCC Part 18, RoHS compliant. 5-year warranty at 70°C max case temp / 3-year warranty at 90°C max case temp. Sold in cases of 10. Verify lamp type, lamp count, and voltage before ordering.

Lamp Count

6 Lamps

F40T8

Dimming

Step

100% / 60%

Ballast Factor

1.18

High Output

System Watts

231W

@ 120V

Min Start Temp

-20°F

Cold Start

Technical Specifications

Brand	GE Lighting — UltraMax LFL
GE Product Code	71497
Description	GE632MAX-H90-S60
Ballast Type	Electronic Step-Dimming — Instant Start
Lamp Count	6 Lamps
Compatible Lamp	F40T8
Input Voltage	120V (±10%), 60Hz
Dimming Type	Bi-level step dimming — 100% / 60%
Start Method	Instant Start
Lamp Wiring	Parallel
System Ballast Factor	1.18 (High Output)
System Watts	231W @ 120V
Nominal Line Current	2.03A
Electrical Efficiency	95%
Power Factor	≥99% (Active Correction)
Crest Factor	≤1.4
THD	≤10%
Sound Rating	Class A (20–24 dB)
Minimum Starting Temperature	-20°F (0°C ambient minimum)
Maximum Case Temperature	70°C (5-yr warranty) / 90°C (3-yr warranty)
Enclosure	Metal
Anti-Striation Control	Yes
Inherent Thermal Protection	Yes
Remote Mounting Distance	Up to 6 feet (18 AWG wire)
Dimensions	11.8" L x 1.7" W x 1.2" H
Weight	3.1 lb
Warranty	5 years (≤70°C) / 3 years (≤90°C)
UPC / EAN	043168714976
Packaging	10 per case
Listings / Compliance	cUL Listed, UL Type CC, UL Type 1 Outdoor, UL Type HL, RoHS, ANSI C82.11, ANSI C62.41, FCC Part 18 Class A

Product Overview

The GE 71497 GE632MAX-H90-S60 UltraMax is a 6-lamp F40T8 step-dimming ballast combining high ballast factor output (1.18) with bi-level switching capability — allowing luminaires to operate at full output (100%) or switch down to 60% for occupancy-based or daylight-harvesting energy management without continuous dimming controls. The 100%/60% step dimming is controlled via the gray wire switching the ballast between high and low output states.

At 95% electrical efficiency and 1.18 ballast factor across 6 lamps, this ballast maximizes lumen delivery per watt — suited for high-ceiling commercial and industrial environments where maximum light output and bi-level control are both required. Parallel lamp wiring keeps remaining lamps operating if one fails. Anti-striation control eliminates visible lamp swirling. UL Type HL listing and UL 55C ambient rating confirm suitability for high-temperature fixture and commercial applications. Remote mounting up to 6 feet allows ballast placement away from the lamp for thermally demanding installations.

Compatible Applications

High-output 6-lamp F40T8 commercial fluorescent fixtures — Warehouses, industrial facilities, gymnasiums, and retail spaces requiring bi-level switching and maximum lumen output.
Occupancy sensor and bi-level switching applications — Step dimming (100%/60%) for energy code compliance and occupancy-based light level reduction.
High-temperature fixture installations — UL 55C high-temperature ambient rating and inherent thermal protection for elevated-temperature applications.
Outdoor and low-temperature installations — UL Type 1 Outdoor rated; -20°F cold start for covered exterior and unheated space applications.

Before Ordering — Verify

Lamp Type: Confirm your lamps are F40T8.
Lamp Count: This is a 6-lamp ballast. Confirm your fixture requires exactly 6 lamps.
Input Voltage: Confirm your circuit is 120V. This is not a universal voltage ballast — confirm voltage before ordering.
Dimming Type: This is a bi-level step-dimming ballast (100%/60%) — not a continuous 0-10V or DALI dimming ballast. Confirm your control system uses switching-based bi-level control.
Ballast Factor: The 1.18 high BF increases system wattage. Confirm high output is appropriate for your application.
Physical Fit: Confirm 11.8" x 1.7" x 1.2" fits within your fixture's ballast cavity.
