GE 75382 GE432-MVPS-N-V03 T8 T8 UltraStart 0-10V Programmed Start Dimming Ballast

Product Overview

GE 75382 GE432-MVPS-N-V03 UltraStart — 3-4 Lamp T8 0-10V Dimming Electronic Ballast, 120-277V, Normal BF 0.88

The GE 75382 GE432-MVPS-N-V03 UltraStart is a 3-4 lamp T8 electronic 0-10V dimming ballast from GE Lighting, designed for commercial T8 fluorescent dimming systems with 0-10V analog control. Universal voltage input covers 120–277V ±10%. Normal ballast factor 0.88, dimming range 100% to 3%, programmed rapid start, parallel lamp circuit, active power factor correction, anti-striation control, Class A sound rating, 70°C maximum case temperature, 104°F maximum ambient, remote mounting up to 5 feet (18 AWG). Compatible with Class 1 or Class 2 0-10VDC controllers. Verify lamp type, lamp count, and input voltage before ordering.

Lamp Count

3–4 Lamps

T8 Fluorescent

Input Voltage

120–277V

±10% Universal

Dimming

0-10V

100% to 3%

Ballast Factor

0.88

Normal Output

Start Type

Programmed

Rapid Start

Technical Specifications

Brand	GE Lighting — UltraStart
GE Order Code	75382
Model	GE432-MVPS-N-V03
Ballast Type	Electronic Dimming — 0-10V
Lamp Count	3 or 4 Lamps
Compatible Lamp Types	F32T8, F32T8/WM, F28T8, F25T8, F17T8
Input Voltage	120–277V (±10%), 50/60Hz
Start Method	Programmed Rapid Start
Dimming Protocol	0-10V (Class 1 or Class 2, 0-10VDC)
Dimming Range	100% to 3%
Lamp Circuit	Parallel
Ballast Factor	0.88 (Normal)
Power Factor Correction	Active
Sound Rating	Class A (20–24 dB)
Anti-Striation Control	Yes
Maximum Ambient Temperature	104°F (40°C)
Maximum Case Temperature	70°C (158°F)
Remote Mounting Distance	Up to 5 feet (18 AWG wire)
Dimensions	9.5" L x 1.7" W x 1.18" H
Weight	1.65 lbs
Exit Type	Side

Product Overview

The GE 75382 GE432-MVPS-N-V03 is the normal ballast factor (0.88) version of GE's UltraStart 0-10V dimming T8 ballast series — the counterpart to the high BF (1.18) GE 75385. At normal output, this ballast delivers full rated lamp lumens without over-driving, making it appropriate for standard commercial lighting designs where energy efficiency and dimming capability are required without inflating system wattage.

Full 100% to 3% dimming range via 0-10V analog controller. Universal voltage operation (120–277V) covers all standard North American commercial circuits. Parallel lamp circuit keeps remaining lamps operating if one fails. Programmed rapid start preheats cathodes before ignition, extending lamp life in high-switching and dimming applications.

Compatible Lamps

(3–4) F32T8 — standard 48" T8
(3–4) F32T8/WM — energy-saving 48" T8
(3–4) F28T8 — 28W T8
(3–4) F25T8 — 36" T8
(3–4) F17T8 — 24" T8

Compatible Applications

0-10V dimming commercial lighting — Daylight harvesting, occupancy-based dimming, and automated lighting control in offices, schools, healthcare, and retail.
Normal output dimming systems — Where full rated lamp lumens at 0.88 BF are appropriate alongside continuous dimming control.
Universal voltage commercial systems — Single SKU covers both 120V and 277V commercial circuits.

Before Ordering — Verify

Dimming Protocol: Requires a 0-10V analog dimming controller — not compatible with DALI, phase-cut, or switching-based bi-level controls.
Ballast Factor: This is the normal (0.88) BF version. For high output (1.18 BF), see GE 75385.
Lamp Count: Confirm fixture requires 3 or 4 lamps.
Lamp Type: Confirm lamps are on the compatible list above.
Input Voltage: Confirm circuit is within 120–277V ±10%.
Physical Fit: Confirm 9.5" x 1.7" x 1.18" fits within your fixture's ballast cavity.

Safety and Installation Guidelines

Disconnect and lock out power before removing or installing a ballast.
Ground the ballast and fixture properly per NEC and local electrical codes.
Do not bundle lamp leads — excess wiring can cause starting or performance issues.
Qualified personnel only — install per applicable electrical codes.
Programmed start requires un-shunted lampholders — verify socket type before installing.
