GE 97598 F18DBX/827/ECO

GE 97598 F18DBX/827/ECO4P – 18W | 2700K Soft White | 1,250 lm | G24q-2 4-Pin

The GE 97598 F18DBX/827/ECO4P is an 18W 2700K Soft White 4-pin plug-in compact fluorescent lamp (4-Pin Double Biax®) delivering 1,250 initial lumens, CRI 82, G24q-2 4-pin base, and 17,000-hour rated life (20,000 hours at 12 hrs). It is a plug-in lamp, not a self-ballasted lamp, and requires a compatible external 4-pin CFL ballast. UPC: 43168975988.

Quick Specs

• Brand: GE
• Order Code: 97598
• GE Description: F18DBX/827/ECO4P
• UPC: 43168975988
• Product Family: 4-Pin Double Biax®
• Wattage: 18W
• Base: G24q-2 (4-pin)
• Nominal Length: 5.8 in
• Color Temperature: 2700K Soft White
• CRI: 82
• Initial Lumens: 1,250 lm
• Mean Lumens: 970
• Rated Average Life: 17,000 hours
• Rated Life @ 12 Hrs: 20,000 hours
• Min. Starting Temperature: Function of the ballast (catalog footnote 6)
• Case Quantity: 50
• TCLP Compliant: Yes (catalog TCLP-compliant plug-in mark)
• EOL Protection: Yes (catalog EOL-protection plug-in mark)
• Lamp Type: Plug-in CFL — not self-ballasted
• Dimming: Not listed in catalog

Product Overview

The GE 97598 F18DBX/827/ECO4P is an 18W 2700K Soft White 4-Pin Double Biax® plug-in CFL rated at 1,250 initial lumens and 970 mean lumens, with a CRI of 82 and a rated average life of 17,000 hours (20,000 hours at 12 hrs). It uses a G24q-2 4-pin base and is a plug-in lamp, so it must be operated on a compatible external 4-pin CFL ballast. Dimming operation is not listed in the GE catalog; do not install on a dimmer circuit unless the ballast manufacturer specifies compatibility.

GE catalog notes for this lamp: Fluorescent lamp lumens decline during life. Based on 60Hz reference circuit. Cold cathode resistance is approximately 6.0 Ohms. 4-Pin lamp minimum starting temperature is a function of the ballast. Most ballasts are rated with a minimum starting temperature of 50°F (10°C). Ballasts are also available that provide reliable starting to 0°F (-18°C) and -20°F (-29°C). Max. bulb wall temperature not to exceed 180°C. Consult GE sales representative for further information. Life ratings are based on operating the lamp on a high frequency electronic rapid start type ballast. GE caution notice 151: CAUTION – Lamp may shatter and cause injury if broken. Remove and install by grasping only the plastic portion of the lamp.

Applications

• 4-pin CFL fixtures – Recessed downlights, wall sconces, and other fixtures built for G24q-2 4-pin plug-in lamps. Confirm base, wattage, and ballast compatibility before ordering.
• Retrofit and maintenance replacement – Like-for-like replacement for 18W G24q-2 lamps. 2700K (Soft White) matches the color temperature of the lamp being replaced when that lamp is also 2700K.

Replacing Your Current 4-Pin CFL?

• Base type – confirm 2-pin vs 4-pin: This lamp uses a G24q-2 4-pin base. 2-pin and 4-pin lamps are not interchangeable. Check your fixture socket.
• Ballast compatibility: Plug-in lamp — requires a compatible external 4-pin CFL ballast rated for 18W and a G24q-2 lamp. The catalog lamp table does not specify a ballast model.
• Wattage – 18W: Confirm your ballast and fixture are rated for 18W.
• Color temperature – 2700K: Match the color temperature of the lamps you are replacing.
• Dimmable: Not listed in the catalog. Do not install on a dimmer circuit unless the ballast manufacturer specifies compatibility.
• Catalog cross-reference: Generic CFQ18W/G24q/827; Osram/Sylvania CF18DD/E/827; Philips PL-C 18W/827/4P/Alto.
• Replaces legacy GE code: 12865 (F18DBX/SPX27/4P) (GE catalog conversion table).

Ordering Information

• Brand: GE
• Order Code: 97598
• GE Description: F18DBX/827/ECO4P
• UPC: 43168975988
• Wattage / CCT: 18W / 2700K Soft White
• Base: G24q-2 (4-pin)
• Case Quantity: 50. Contact ADL Supply for volume orders.

Compliance

• TCLP compliant plug-in lamp per the GE catalog.
• EOL protection plug-in lamp per the GE catalog.
• Caution notice 151: lamp may shatter and cause injury if broken; remove and install by grasping only the plastic portion of the lamp.
• This lamp contains mercury — dispose per local lamp recycling regulations. Visit lamprecycle.org.

For wholesale pricing, bulk availability, or help confirming the correct replacement lamp, contact ADL Supply at 1-800-235-3489.

ADL Supply recommends confirming all specifications with the manufacturer product data sheet prior to installation.
