Halco HiLED20-840-E26 LED HID Filament Lamp | 20W | 4000K

Product Overview

Halco HiLED20-840-E26 84898 — 20W LED HID Filament Lamp, ED23.5 E26 (Medium), 4000K, 3,600 lm — Replaces 70W HID

The Halco HiLED20-840-E26 (SKU 84898) is a Type B ballast-bypass LED filament lamp engineered to directly replace a 70W HID lamp. Built on a durable full-glass ED23.5 bulb with a E26 (Medium) base, it uses high-power LED filament technology to reproduce the look, 360° light distribution, and omnidirectional beam pattern of a traditional HID lamp, so it works with existing fixture reflector optics. It delivers 3,600 lm at 180 lm/W. Rated 4000K with CRI >80, this lamp is ETL wet-location listed and carries a 5 Years limited warranty. The existing fixture must be rewired to bypass the ballast before installing this lamp.

WATTAGE

20W

Replaces 70W HID

LUMENS

3,600 lm

180 lm/W

COLOR TEMP

4000K

CRI >80

BASE

E26 (Medium)

ED23.5

RATED LIFE

>50,000h

5 Years Warranty

Technical Specifications

Brand	Halco Lighting Technologies
Halco Product Code	HiLED20-840-E26
Halco Product SKU	84898
Series	HiLED (LED HID Filament Lamp)
Ballast Type	Type B Ballast Bypass (no ballast required)
Bulb Shape	ED23.5
Base Type	E26 (Medium)
Input Voltage	120-277V
Wattage	20W
Equivalent Wattage (HID Replaced)	70W
Delivered Lumens	3,600 lm
Efficacy	180 lm/W
Color Temperature (CCT)	4000K
Color Rendering Index (CRI)	>80
Beam Angle	360°
L70 Rated Life	>50,000 hours
Power Factor	0.9
Dimmable	No
Lens	Glass
Operating Temperature Range	-30°C to 45°C
Diameter	2-15/16"
Maximum Overall Length (MOL)	7-11/16"
Weight	0.44 lbs
Operating Position	Universal
Frequency	50/60Hz
Environment Rating	Wet Location
Listings	cETLus, FCC, RoHS compliant; Wet Location Rated
Warranty	5 Years Limited Warranty

Product Overview

The Halco HiLED20-840-E26 is part of Halco's HiLED LED HID Filament Lamp series, a Type B ballast-bypass line built to replace traditional HID (metal halide/HPS) lamps with LED filament technology housed in a clear, full-glass envelope. Because the fixture's existing ballast is bypassed entirely, this lamp draws power directly from the 120-277V line, cutting both energy use and the maintenance burden of a failing ballast.

Rated >50,000 hours to L70 with a 5 Years limited warranty, it carries a 360° beam angle to match the omnidirectional distribution of the HID lamp it replaces, and is ETL listed for wet locations.

Compatible Applications

Office parks and exterior building lighting.
Commercial buildings and commercial maintenance facilities.
Self storage facilities.
K-12 schools and higher education campuses.
Cargo bays and loading docks.
Any fixture currently running a 70W HID (metal halide or HPS) lamp where the ballast can be bypassed.

Before Ordering – Verify

Ballast bypass rewiring is required. This is a Type B lamp — the existing ballast must be disconnected/bypassed before installing it; it is not a plug-and-play ballast-compatible retrofit.
Confirm the fixture currently runs a 70W HID lamp before ordering — this lamp is sized and rated as that lamp's replacement.
Confirm the fixture uses a E26 (Medium) socket.
Confirm the 4000K color temperature is correct for the application — Halco also offers this bulb shape/wattage in other CCTs.
Not dimmable. Do not connect to a dimming circuit or control.
Verify diameter (2-15/16") and length (7-11/16") clear the fixture housing.

Safety and Handling Guidelines

Disconnect power at the breaker before installing or servicing.
Ballast bypass wiring should be performed by a qualified electrician familiar with rewiring HID fixtures for Type B LED lamp operation.
Do not connect to a dimmer or other lighting control — this lamp is not dimmable.
Allow the fixture to cool before handling after operation.
Do not install a lamp with cracked, loose, or otherwise damaged glass.
This is an LED lamp and contains no mercury; dispose of/recycle per local electronics-waste regulations.
