Ushio 1000848 JC24V-50W G6.35

Product Overview

Ushio 1000848 JC24V-50W — 50W 24V T3.5 Halogen Capsule Lamp, 2950K, G6.35 Bi-Pin

The Ushio 1000848 JC24V-50W is a 50-watt, 24-volt T3.5 single-ended halogen capsule lamp from Ushio, designed for approved enclosed low-voltage halogen fixtures. With a G6.35 miniature bi-pin base, 2950K warm white color temperature, CRI 100, 750 lumens, C-6 filament, universal burn position, and a 2,000-hour rated life, this lamp is suited for specialty commercial, medical, and professional lighting applications requiring 24V halogen capsule sources. Verify voltage, wattage, and base type before ordering.

Wattage

50W

Halogen T3.5

Lumens

750 lm

Initial Output

Color Temp

2950K

Warm White

Base

G6.35

Miniature Bi-Pin

Rated Life

2,000 hrs

Average Life

Technical Specifications

Brand	Ushio
Ushio Item Code	1000848
Description	JC24V-50W-G6.35
Lamp Type	T3.5 Single-Ended Halogen Capsule
Wattage	50W
Voltage	24V
Initial Lumens	750 lm
CRI	100
Color Temperature	2950K Warm White
Base Type	G6.35 Miniature Bi-Pin
Filament	C-6
Burn / Operating Position	Universal
Rated Average Life	2,000 hours
Max Overall Length (MOL)	1.73"
Bulb Diameter	43mm
Fixture Requirement	Approved enclosed halogen fixtures only

Product Overview

The Ushio 1000848 JC24V-50W is a compact halogen capsule lamp for low-voltage specialty fixtures operating at 24V. At 50W with 750 lumens, 2950K warm white, and CRI 100, this lamp delivers full-spectrum halogen illumination for commercial, medical, and professional applications requiring precise, warm color rendering in a compact T3.5 envelope.

The G6.35 miniature bi-pin base provides a secure connection in low-voltage halogen lampholders. Universal burn position allows installation in any orientation. Requires a 24V power supply — confirm transformer or electronic driver output is exactly 24V before installation. Approved enclosed halogen fixtures only.

Compatible Applications

Medical and dental equipment — Low-voltage halogen capsule sources for examination, surgical, and instrument lighting where 24V G6.35 lamps are specified.
Commercial specialty lighting — Enclosed low-voltage halogen fixtures in retail, hospitality, and professional environments.
Fiber optic and optical equipment — Specialty instruments requiring 24V halogen capsule sources with precise color rendering.
Retrofit and maintenance replacement — Direct replacement for JC24V-50W G6.35 designated lamps in compatible fixtures.

Before Ordering — Verify

Voltage: Confirm equipment transformer output is 24V. Do not connect to 120V mains without a transformer.
Wattage: Confirm the fixture is rated for 50W.
Base Type: Confirm the lampholder accepts G6.35 Miniature Bi-Pin — not GY6.35 or GZ6.35.
Physical Fit: Confirm 1.73" MOL and 43mm diameter fit within your fixture's lamp housing.
Fixture Type: Use only in approved enclosed halogen fixtures.

Safety and Handling Guidelines

Do not touch the quartz envelope with bare hands. Skin oils cause hot spots leading to premature failure. Use clean gloves or a lint-free cloth. If accidentally touched, clean with isopropyl alcohol before use.
Approved Enclosed Fixtures Only: Do not use in open or unshielded fixtures.
Do not exceed 24V. Operating above rated voltage shortens lamp life.
Allow Cooling: Allow the lamp to cool fully before handling or replacement.
Handle with Care: Inspect for cracks or damage before installation. Do not use a damaged lamp.
