Product Overview
Ushio 1000839 JC24V-100W – 100W | 24V | 3000K Warm White | G6.35 Miniature Bi-Pin
The Ushio 1000839 JC24V-100W is a 100W 24V halogen miniature lamp with G6.35 Miniature Bi-Pin base, 3000K Warm White color temperature, CRI 100, 2,000 hours rated life. UPC: 48777155165.
Wattage 100W Halogen JC M | Voltage 24V Operating | Color Temp 3000K CCT | Lumens — Initial lm | Rated Life 2,000 Hours |
Quick Specs
- Brand: Ushio
- Ushio Catalog Number: 1000839
- UPC: 48777155165
- Lamp Type: Halogen JC Miniature — G6.35/GY6.35 Bi-Pin
- Wattage: 100W
- Operating Voltage: 24V
- Color Temperature: 3000K Warm White
- CRI: 100
- Rated Average Life: 2,000 hours
- Base Type: G6.35 Miniature Bi-Pin
- Overall Length (MOL): 1.73in x DIA 43mm
- Burn / Operating Position: Position
Product Overview
The Ushio 1000839 JC24V-100W is a 100W 24V halogen miniature lamp with G6.35 Miniature Bi-Pin base for instrument lighting, task lighting, fiber optic illuminators, and specialty optical applications. At 3000K Warm White with CRI 100 this lamp provides high-quality illumination. Rated life: 2,000 hours.
Do not touch the quartz envelope with bare hands.
Applications
- Instrument lighting — Instrument lighting, task lighting, fiber optic illuminators, and specialty optical applications.
- Retrofit and maintenance replacement – Confirm lamp type, wattage, voltage, and base before ordering.
Safety and Handling
- Do not touch the lamp envelope with bare hands. Skin oils cause hot spots leading to premature failure. Use clean gloves or lint-free cloth.
- Voltage — 24V: Verify supply matches rated voltage.
- Enclosed fixture only. Use only in approved enclosed fixtures.
- Allow 15-minute cool-down before replacement.
Ordering Information
- Brand: Ushio
- Ushio Catalog #: 1000839
- ANSI Code: —
- UPC: 48777155165
- Wattage / Voltage: 100W / 24V
- Base: G6.35 Miniature Bi-Pin
- Case quantities and bulk pricing: Contact ADL Supply for volume orders.
Compliance
- Halogen lamp — no mercury content. Standard electronic waste disposal applies.
- Verify RoHS and Prop 65 compliance with Ushio specification sheet.
ADL Supply recommends confirming all specifications with the Ushio product data sheet prior to installation.
