Ushio 1000089 BVE JCS120V-625W

Ushio 1000089 BVE JCS120V-625W – 625W 120V Halogen Lamp

The Ushio 1000089 BVE JCS120V-625W is a 625-watt, 120-volt halogen lamp with a 2-Pin Prefocus Base (GY9.5). Ushio lists it with a 75-hour average life and a 3350K color temperature.

This lamp is identified by the BVE lamp code and is listed under Ushio description JCS120V-625W.

Product Overview

The Ushio 1000089 is a JCS-series halogen lamp listed in the Halogen Bi-Pin • SSTV & AV section of the Ushio halogen catalog. Per Ushio, this lamp is for use only in approved enclosed halogen fixtures.

Always confirm the lamp code, wattage, voltage, base type, and burn position against your existing lamp or equipment manual before ordering.

Why Choose This Product

• BVE Lamp Code: Helps match the lamp to equipment specified for this lamp code.
• 625W at 120V: Wattage and voltage as published by Ushio for catalog number 1000089.
• Published Output: 3350K color temperature per the Ushio catalog.
• 75-Hour Rated Life: Ushio’s published average life for this lamp.
• GY9.5 Base: 2-Pin Prefocus Base (GY9.5).
• Burn Position: Base Down to Horizontal (BD/Hor).

Technical Specifications

Compatible Applications

• Fixtures and equipment specified for the BVE JCS120V-625W lamp
• Equipment in the SSTV & AV category, as listed in the Ushio catalog
• Maintenance replacement where voltage (120V), wattage (625W), base (GY9.5), and burn position all match
• Approved enclosed halogen fixtures only, as required by Ushio

Cross Reference Numbers

• Ushio Catalog Number: 1000089
• ANSI / Common Lamp Code: BVE
• Manufacturer Description: JCS120V-625W
• UPC: 048777105887
• Common Search Terms: BVE lamp, BVE JCS120V-625W, JCS120V-625W, 625W 120V halogen lamp

Before Ordering Verify

• Voltage: This lamp is rated for 120V operation. Do not install in fixtures requiring a different voltage.
• Wattage: Confirm your equipment is rated for a 625W lamp.
• Base Type: Confirm the socket matches the 2-Pin Prefocus Base (GY9.5).
• Burn Position: Ushio lists this lamp for base down to horizontal (bd/hor) operation; confirm it matches how your fixture holds the lamp.
• Dimensions: Ushio lists a maximum overall length of 89.0 mm and a bulb diameter of 19.5 mm; confirm they fit your fixture.
• Lumens: Ushio does not publish an initial lumen rating for this catalog number. Contact ADL Supply if light output is critical to your application.

Important Safety & Installation Notes

• Do Not Touch the Bulb With Bare Hands: Skin oils can create hot spots that may cause premature failure. Use clean gloves or a lint-free cloth.
• Use Approved Fixtures Only: Ushio specifies this lamp for use only in approved enclosed halogen fixtures. Install only in equipment designed for this lamp type, wattage, and voltage.
• Allow Cooling Before Replacement: Let the lamp and fixture cool before handling or replacing.
• Verify Voltage Before Installing: Operating above rated voltage can significantly shorten lamp life or cause lamp failure.
• Disconnect Power: Turn off and disconnect power before installing or removing the lamp.
