Product Overview
OSRAM DULUX D/E 10 W/840 G24q-1 4-Pin Compact Fluorescent Lamp
The DULUX D/E 10 W/840 is an OSRAM four-pin compact fluorescent lamp from the DULUX D/E family. The supplied OSRAM catalog lists a G24q-1 base, 600 lumens, color code 840, and a maximum lamp length of 87 mm.
|
Wattage
10W
Lamp Power
|
Lumens
600 lm
Rated Output
|
CCT
4000K
Cool White
|
Base
G24q-1
4-Pin Plug-In
|
CRI
80–89
Color Rendering
|
Technical Specifications
| Brand | OSRAM |
| Series | DULUX D/E |
| Product Reference | DULUX D/E 10 W/840 |
| Product Number / EAN | 4050300017587 |
| Wattage | 10W |
| Luminous Flux | 600 lm |
| Color Code | 840 |
| Correlated Color Temperature | 4000K |
| Light Color | LUMILUX Cool White |
| Base Type | G24q-1 (4-Pin) |
| Maximum Lamp Length | 87 mm |
| Color Rendering Index (CRI) | 80–89 |
| Control Gear | Separate electronic control gear (ECG); supports dimming with compatible gear |
Product Overview
Designed for professional luminaires, this lamp uses a single-ended four-pin plug-in base. Its listed light output is 600 lumens with LUMILUX Cool White color performance and a CRI of 80–89.
Control gear: Separate electronic control gear (ECG); supports dimming with compatible gear. Always confirm ballast/control-gear compatibility before ordering or installing.
Compatible Applications
- Department stores
- Office buildings
- Dimming applications
- Battery- or solar-powered emergency lighting with compatible ECGs
Before Ordering – Verify
- Verify the base: this lamp requires a G24q-1 four-pin socket.
- Verify wattage: 10W.
- Verify color code: /840 (4000K).
- Verify control gear: Separate electronic control gear (ECG); supports dimming with compatible gear.
- Confirm the fixture can accept a lamp up to 87 mm in maximum length.
Safety and Handling Guidelines
- Disconnect power before installing or removing the lamp.
- Allow the lamp to cool before handling.
- Install only in a compatible socket and with compatible control gear.
- Handle the glass tubes carefully and follow applicable fluorescent-lamp recycling requirements.
Compliance
- The supplied OSRAM catalog identifies this product by EAN 4050300017587, wattage, base, light output and color designation.
- No separate third-party certification listing is stated on the supplied catalog page; verify project-specific requirements before ordering.
Ordering Information
- OSRAM Product Reference: DULUX D/E 10 W/840
- Manufacturer Product Number / EAN: 4050300017587
- Base: G24q-1 4-pin
- Color: 4000K / LUMILUX Cool White
For wholesale pricing, bulk availability, or help confirming the correct replacement lamp, contact ADL Supply at 1-800-235-3489.
