Halco 71103 Q250DC/120 250W 120V T4 Frosted Halogen Lamp (BA15d)
The Halco 71103 (Q250DC/120) is a 250W, 120V frosted single-ended JD-type halogen lamp with a T4 bulb and BA15d (DC Bayonet) base. Halco rates it at 4,200 lumens and 2950K with a 2,000-hour average life.
Wattage 250W Halogen | Voltage 120V Rated | Output 4,200 lm Lumens | Color Temp 2950K Warm White | Rated Life 2,000h Average |
Performance and Features
- Light Output: 4,200 lumens from a 250W lamp at 120V.
- Color Temperature: 2950K halogen light.
- Rated Life: 2,000 hours average.
- Single-Ended Design: T4 JD-type bulb with a BA15d (DC Bayonet) base, frosted finish and 2.76" maximum overall length.
- Filament: CC-8 coiled-coil design filament.
Technical Specifications
- Brand: Halco
- Halco Product Number: 71103
- Product Code: Q250DC/120
- ANSI Code: ETB
- Bulb Shape: T4 (JD type)
- Base Type: BA15d (DC Bayonet)
- Wattage: 250W
- Voltage: 120V
- Lumens: 4,200
- Color Temperature: 2950K
- Average Life: 2,000 hours
- Design Filament: CC-8
- Maximum Overall Length: 2.76"
- Description: Frost
- Package Quantity: 10/200
- HS Tariff Code: 8539390000
Packaging and Ordering
Halco lists package quantity 10/200 for this lamp. Order by Halco product number 71103 (also known by ANSI code ETB).
Safety and Handling
Important Installation Notes
- Do not touch the capsule with bare hands; skin oil can reduce performance unless wiped clean with alcohol and a soft cloth. The lamp operates under pressure and could shatter, so use it in a fixture with a protective shield or tempered glass, with adequate ventilation, and only in fixtures rated for the stated wattage. Turn power off and let the lamp cool before replacing. Socket condition may affect lamp life; inspect and replace the socket if it deteriorates.
Before Ordering - Verify
- Confirm your fixture is rated for 250W / 120V / BA15d before ordering; voltage and base must match exactly.
Order from ADL Supply
ADL Supply is a wholesale commercial and industrial lighting distributor. Need help confirming fit or availability? Call us at 1-800-235-3489.
