GE 11750 EXX 120V 250W

GE 11750 EXX — 250W 120V MR16 Projection Lamp, GX5.3 2-Pin Base

The GE EXX (order code 11750) is a 250W projection lamp rated at 120 volts, built on a MR16 bulb with a GX5.3 2-Pin base and a CC-8 filament. Rated life is 25 hours. Colour temperature is 3300K. Initial output is 6750 lumens. Centre beam candlepower is 6750 candelas. Maximum overall length is 1.75 in. The lamp may be operated in any position. Typical application: Camera Light. Projection lamps are matched to specific optical systems — confirm the ANSI code, base, light centre length, and burn position against the equipment before ordering.

Technical Specifications

Product Overview

Projection lamps are precision optical sources. Unlike general lighting lamps, they are built with tailored filaments positioned to close tolerances so that the light source sits exactly where the equipment's optical system expects it. That is why light centre length and burn position appear on the specification alongside wattage and voltage: a lamp with the right base and wattage but the wrong filament position will not focus correctly.

This is a reflector lamp built on a MR-16 faceted dichroic reflector, 2 in (51mm) diameter. GE Multi-Mirror® and reflector Quartzline® lamps combine a halogen filament tube with a precision reflector assembled to a rim reference, so the lamp snaps into alignment on installation rather than requiring adjustment. The dichroic coating passes infrared rearward through the reflector instead of forward with the beam, giving a cool beam that reduces heat load on film, artwork, or specimens in the optical path. The faceted reflector produces an efficient, uniform beam with precise control.

Compatible Applications

• Camera Light (GE listed application)
• Slide, 8mm, and 16mm projectors
• Microfilm readers
• Fibre optic illuminators
• Medical and scientific instruments
• Camera and video lighting
• Replacement lamp for equipment specified with ANSI code EXX

Before Ordering — Verify

• Confirm the equipment calls for ANSI code EXX. ANSI codes assure mechanical and electrical interchangeability between manufacturers, so this is the primary cross-reference.
• Confirm the base is GX5.3 2-Pin.
• Confirm the supply is 120V. Supply voltage variation significantly affects lamp life.
• Confirm the equipment accommodates a maximum overall length of 1.75 in. Listed lengths include maximum tolerances, so actual lamps are generally slightly shorter.
• Confirm the equipment holds the lamp in a permitted burn position. This lamp is rated U: Universal — operate in any position.
• Note the 25 hour rated life when planning spares. Rated life is a laboratory median at rated voltage, not a service life guarantee — shock, vibration, voltage fluctuation, and temperature can all shorten it.
• Confirm case quantity — the manufacturer case quantity for this order code is 20.
• GE lists warning and caution notice A against this lamp. Refer to GE's published notices for this order code before installation.

Safety and Handling Guidelines

• Disconnect power and allow the lamp to cool completely before handling or replacement. Projection lamps run at high temperature and stay hot well after switch-off.
• Do not touch the quartz envelope with bare hands. Skin oils cause localized overheating of the quartz and can lead to premature failure or rupture. Clean with isopropyl alcohol if the envelope is touched.
• Quartz halogen lamps operate under pressure. Operate only within an enclosed housing or the equipment for which the lamp is specified.
• Seat the lamp fully in its socket. A partially seated lamp can arc at the contacts and overheat the lampholder.
• Ensure the equipment provides the cooling airflow it was designed with. Projection lamps depend on forced or convected air to stay within their thermal limits.
• Keep combustible materials clear of the lamp and lamphouse.
• Do not exceed the rated voltage. Overvoltage operation sharply reduces lamp life.
• Follow the equipment manufacturer's instructions for lamp installation and alignment.
• This lamp contains no mercury. Recycle or dispose of it in accordance with local requirements.

Compliance

• GE warning and caution notice reference: A. Refer to GE's published notices for this order code before specification or installation.
• Contains no mercury. Not subject to mercury lamp disposal or shipping restrictions.
• Rated life is stated per ANSI standard design life.
• Dispose of in accordance with local regulations.

Ordering Information

• Brand: GE Lighting
• Order Code: 11750
• Description / ANSI Code: EXX
• Family: Quartzline® Multi-Mirror® Reflector
• Case Quantity: 20
• Lamp: 250W, 120V, MR16 bulb, GX5.3 2-Pin base, CC-8 filament
• Dimensions: 1.75 in MOL
• Rated Life: 25 hours
• Burn Position: U
• Related lamps in this family: BAB/PH (20W 12V, order code 10933); DDL (150W 20V, order code 43537); DDM (80W 19V, order code 43206); DDS (80W 21V, order code 43988); DED (85W 13.8V, order code 43950); DJT (50W 13.8V, order code 44854); EFM (50W 8V, order code 21276); EFN (75W 12V, order code 21277)
