GE 42697 CYV-Q1000T7/4CL/BP – 120W/120V Quartzline Halogen SSTV Lamp | ANSI CYV | 3200K | 28,500 Lumens | G38 Base

28,500 lumens at 3200K with CRI 100 – a high-output 120W Quartzline halogen SSTV lamp with G38 mogul bi-post base for stage, studio, and entertainment lighting.

Quick Specs

• Brand: GE (General Electric)
• SKU / Order Code: PYLBGCYV697
• ANSI Code: CYV
• Lamp Type: Quartzline Halogen (SSTV)
• Wattage: 120W
• Voltage: 120V
• Base Type: G38 (Mogul Bi-Post)
• Color Temperature: 3200K (Studio White)
• CRI: 100
• Initial Lumens: 28,500 lm
• Rated Average Life: 200 hours
• Filament Type: C-13
• Maximum Overall Length (MOL): 203 mm (8.0 in)
• Bulb Diameter: 21.6 mm (0.85 in)

Product Overview

The GE 42697 CYV Quartzline Halogen Lamp is a 120-watt, 120-volt SSTV lamp delivering 28,500 initial lumens at 3200K studio white with CRI 100. This high-output halogen source is designed for professional stage, studio, and entertainment lighting fixtures requiring compact, intense light with perfect color rendering.

The G38 mogul bi-post base provides secure electrical and mechanical contact, while the C-13 filament configuration is optimized for specific optical systems in professional luminaires. With a 200-hour rated life, this lamp is ideal for applications where maximum lumen output per watt is prioritized over extended life – typical in high-intensity follow spots, ellipsoidal spotlights, and Fresnel fixtures.

Why Choose This Product

• 28,500 lumens from 120W – exceptional efficiency: Delivers approximately 237 lumens per watt, making it one of the most efficient halogen lamps in its class for stage and studio use.
• ANSI CYV – industry-standard replacement: The CYV ANSI code guarantees consistent electrical and photometric performance for compatible fixtures.
• 3200K studio white – broadcast-matched color: Camera systems set to 3200K tungsten white balance reproduce colors accurately under this lamp.
• CRI 100 – perfect color rendering: Continuous-spectrum halogen light renders all colors without gaps – essential for professional video, film, and live events.
• G38 mogul bi-post base: Provides secure, high-current connection for reliable operation in professional luminaires.
• Compact T7 bulb shape: 21.6mm diameter fits tight optical systems in ellipsoidal spotlights and follow spots.

Technical Specifications

Dimensions

Applications

• Stage and theater lighting – ellipsoidal spotlights, follow spots, Fresnel fixtures
• Studio and entertainment production – high-intensity key and fill lighting
• Concert and live event lighting systems
• Professional luminaires requiring G38 mogul bi-post base

Compatibility & Replacement

Fixture type: This ANSI CYV lamp fits professional stage and studio fixtures designed for a G38 mogul bi-post base and 120W/120V halogen lamps. Common in certain ellipsoidal spotlights, follow spots, and specialty luminaires from manufacturers like Altman, Strand, and Selecon.

Base: G38 mogul bi-post – a two-pin base with 38mm spacing between contacts, larger than G9.5/GY9.5. Confirm your fixture uses G38 lampholders.

Ballast: No ballast required – operates directly on 120V mains power.

Before ordering, confirm:

• ANSI code – CYV: Verify your fixture specifies ANSI CYV lamp type.
• Voltage – 120V: Verify fixture and supply circuit are 120V.
• Base type – G38: Physically confirm your fixture uses G38 mogul bi-post lampholders (not G9.5, GX38, or other variants).
• Physical dimensions: Verify your fixture accepts a T7 bulb with 203mm overall length and 21.6mm diameter.
• Fixture wattage rating: Ensure fixture is rated for at least 120W.
• Burn position: Consult fixture documentation for approved orientation – not specified by manufacturer for this lamp.

Ordering Information

• Brand: GE (General Electric)
• SKU / Order Code: PYLBGCYV697
• ANSI Code: CYV
• UPC: 043168886307
• Lamp Type: 120W/120V Quartzline Halogen SSTV – G38 Base, T7, 3200K, 28,500 lm
• Case quantities and bulk pricing available – contact ADL Supply for volume orders.

Compliance & Certifications

• Verify UL / ETL listing status with manufacturer specification sheet.
• Verify RoHS compliance status with manufacturer specification sheet.
• Verify FDA radiation performance compliance with manufacturer specification sheet.
• Verify Prop 65 warning requirements with manufacturer specification sheet.

ADL Supply recommends confirming all applicable compliance data with the GE official product data sheet (ANSI CYV / SKU PYLBGCYV697) prior to specification or installation.

Safety & Handling Notes

• High pressure warning – face shield required: SSTV lamps operate under high internal pressure. Always wear a face shield and protective gloves during handling and installation. Lamp burst can cause serious injury.
• No bare hands: Never touch the bulb envelope with bare skin. Oils cause hot spots leading to premature failure or lamp burst. Use clean gloves or a lint-free cloth.
• Do not exceed rated voltage: Operating above 120V dramatically shortens lamp life. Verify supply voltage before installing.
• Burn position: Observe the rated burn position as specified by your fixture. Incorrect orientation can cause premature failure or lamp burst.
• Extreme heat and UV output: Use only in approved enclosed luminaires with appropriate UV filtering.
• Allow complete cool-down before handling: Allow lamp to cool completely before relamping. Do not touch immediately after switching off.
• Follow your fixture manufacturer's service documentation for lamp replacement procedures.
