GE Q250MC-ESM Quartzline Halogen Lamp – 250W 120V SSTV Stage & Studio | ANSI ESM | 2950K | CC-8 Filament | 2000hr Life

4,850 lumens at 2950K with CRI 100 and 2000-hour long life – a 250W/120V Quartzline halogen SSTV lamp with E11 mini candelabra base, frosted T4 bulb, and CC-8 filament for stage, studio, theater, and broadcast lighting.

Quick Specs

• Brand: GE Lighting
• Series: Quartzline
• Model / Order Code: Q250CL/MC
• ANSI Code: ESM
• Product Code: 43695
• UPC: 043168436953
• Lamp Type: Halogen SSTV (Stage, Studio & Theater)
• Wattage: 250 W
• Voltage: 120 V
• Base Type: E11 (Mini Candelabra Screw)
• Bulb Shape: T4
• Bulb Color: Frosted
• Color Temperature: 2950K
• CRI: 100
• Initial Lumens: 4,850 lm
• Rated Life: 2,000 hours
• Filament Type: CC-8
• Dimmable: Yes
• Maximum Overall Length (MOL): 3.16 in (80.3 mm)
• Bulb Diameter: 0.5 in (12.7 mm)
• Burn Position: Not specified (verify with fixture documentation)

Product Overview

The GE Quartzline Q250MC-ESM (Q250CL/MC) is a professional 250-watt, 120-volt SSTV halogen lamp delivering 4,850 initial lumens at 2950K with CRI 100. It features an E11 mini candelabra screw base and a frosted T4 bulb, making it ideal for stage, studio, theater, and broadcast fixtures where a warm white, long-life halogen source is required.

GE Quartzline halogen SSTV lamps are widely used in professional stage fixtures, television studios, film production, and theater lighting. The 2,000-hour rated life significantly reduces maintenance frequency compared to standard stage lamps, while the CC-8 filament provides stable, intense light output. The frosted finish helps diffuse light for smoother beam quality.

Why Choose This Product

• 4,850 lumens – high output for 250W: Excellent brightness for ellipsoidal spotlights, Fresnel fixtures, and accent lighting.
• 2,000-hour long life – low maintenance: Extended service life reduces relamping costs and downtime.
• 2950K warm white color temperature: Provides a natural tungsten ambiance ideal for theatrical and broadcast environments.
• CRI 100 – perfect color rendering: Full-spectrum halogen light ensures accurate color reproduction.
• E11 mini candelabra base: Compact screw base compatible with smaller stage and studio fixtures.
• Frosted T4 bulb: Reduces glare and provides even illumination.

Technical Specifications

Dimensions

Applications

• Stage lighting systems – ellipsoidal spotlights, Fresnel fixtures, border lights
• Studio lighting – key, fill, and backlighting for television and video production
• Theater lighting – front-of-house and on-stage fixtures
• Broadcast and video production – news studios, interview sets
• Professional entertainment lighting fixtures – concerts, houses of worship, live events

Compatibility & Replacement

Fixture type: This ANSI ESM lamp is designed for professional stage and studio fixtures that accept an E11 mini candelabra base and 250W/120V halogen lamps. Common in smaller ellipsoidal spotlights, accent fixtures, and specialty luminaires.

Base: E11 (Mini Candelabra Screw) – smaller than standard E26 base. Confirm your fixture uses E11 lampholders.

Ballast: No ballast required – operates directly on 120V mains power.

Before ordering, confirm:

• ANSI code – ESM: Verify your fixture specifies ANSI ESM or equivalent.
• Voltage – 120V: Verify fixture and supply circuit are 120V.
• Base type – E11: Physically inspect your existing lamp or fixture lampholder to confirm E11 base.
• Physical dimensions: Verify your fixture accepts a T4 bulb with 3.16-inch overall length and 0.5-inch diameter.
• Fixture wattage rating: Ensure fixture is rated for at least 250W.
• Burn position: Consult your fixture documentation for approved lamp orientation (not specified by manufacturer).

Ordering Information

• Brand: GE Lighting
• Product Code: 43695
• Order Code: Q250CL/MC
• Model: Q250MC-ESM
• ANSI Code: ESM
• UPC: 043168436953
• Lamp Type: 250W/120V Quartzline Halogen – E11 Base, Frosted T4, 2950K, 4,850 lm, 2,000 hr life
• Case quantities and bulk pricing available – contact ADL Supply for volume orders.

Compliance & Certifications

• Verify UL / ETL listing status with manufacturer specification sheet.
• Verify RoHS compliance status with manufacturer specification sheet.
• Verify FDA radiation performance compliance with manufacturer specification sheet.
• Verify Prop 65 warning requirements with manufacturer specification sheet.

ADL Supply recommends confirming all applicable compliance data with the GE official product data sheet (ANSI ESM / Product Code 43695) prior to specification or installation.

Safety & Handling Notes

• High pressure warning – face shield required: Quartzline halogen lamps operate under high internal pressure. Always wear a face shield and protective gloves during handling and installation. Lamp burst can cause serious injury.
• No bare hands: Never touch the quartz envelope with bare skin. Oils cause hot spots leading to premature failure or lamp burst. Use clean gloves or a lint-free cloth.
• Do not exceed rated voltage: Operating above 120V dramatically shortens lamp life. Verify supply voltage before installing.
• Burn position: Observe the rated burn position as specified by your fixture manufacturer (not provided – consult fixture documentation).
• Extreme heat and UV output: Use only in approved enclosed luminaires with appropriate UV filtering.
• Allow complete cool-down before handling: Allow lamp to cool completely before relamping. Do not touch immediately after switching off.
• Follow your fixture manufacturer's service documentation for lamp replacement procedures.
