Sylvania 54631 FRK 120V 650W – 650W/120V | 3200K Warm White | GY9.5 Bipin

The Sylvania 54631 FRK 120V 650W is a 650W 120V SSTV (Stage, Studio & Theater) halogen lamp delivering Verify lumens with manufacturer specification sheet, CRI 100, base, rated life: verify with data sheet, color temperature. UPC: 046135546310.

Quick Specs

• Brand: Sylvania
• Item / Catalog Number: FRK-120V650W
• UPC / EAN: 046135546310
• Lamp Type: SSTV Halogen — Stage, Studio & Theater
• Wattage: 650W
• Base Type: GY9.5 Bipin
• Color Temperature: 3200K Warm White
• Operating Voltage: 120V
• CRI: 100
• Rated Average Life: Verify with manufacturer specification sheet
• Overall Length (MOL): 3.51in x DIA 0.75
• Filament: C-13D

Product Overview

The Sylvania 54631 FRK 120V 650W is a 650W 120V SSTV halogen lamp for professional stage, studio, and theater lighting applications. At with CRI 100, the C-13D filament delivers consistent photometric output appropriate for film, broadcast, and live performance fixtures requiring maximum tungsten output at rated voltage.

Operating at 120V requires correct voltage supply — operating above rated voltage significantly shortens lamp life in an already short (—-hour) service cycle. Do not touch the quartz envelope with bare hands — skin oils cause hot spots leading to premature failure. Use gloves or lint-free cloth; clean with isopropyl alcohol if touched.

Applications

• Stage and theatrical lighting – Professional fixtures including ellipsoidals, Fresnels, and PAR units requiring 650W 120V halogen at .
• Film and broadcast production – Studio and on-set fixtures where tungsten-balanced halogen output at matches camera white balance requirements.
• Concert and touring lighting – Touring production rigs requiring reliable high-output halogen replacement at 120V operating voltage.

Replacing Your Current SSTV Halogen Lamp?

• Voltage — 120V: This lamp is rated 120V. Verify your fixture supply circuit is 120V. Operating above rated voltage shortens lamp life significantly.
• Base type — : Verify your fixture uses lampholders. Note that G9.5, GY9.5, and GX9.5 are different pin specifications — confirm the exact designation with fixture documentation.
• Do not touch quartz envelope with bare hands: Skin oils cause hot spots leading to premature failure or lamp burst. Use gloves or lint-free cloth. Clean with isopropyl alcohol if touched accidentally.
• Allow cool-down before replacement: Allow at least 15 minutes after switch-off before handling.

Ordering Information

• Brand: Sylvania
• Item / Catalog Number: FRK-120V650W
• UPC / EAN: 046135546310
• Wattage / Voltage: 650W / 120V
• Base:
• Case quantities and bulk pricing: Contact ADL Supply for volume orders.

Safety and Compliance

• Verify RoHS compliance with manufacturer specification sheet.
• Verify applicable FDA radiation performance compliance for your application.
• Verify Prop 65 warning requirements with manufacturer specification sheet.
• This lamp contains mercury — dispose per local lamp recycling regulations. Visit lamprecycle.org.

ADL Supply recommends confirming all specifications with the manufacturer product data sheet prior to specification or installation.
