Sylvania 69261 XBO 900 W OFR – 900W | 6000K Daylight White | 30,000 Lumens | CRI 98 | 19V DC | 45 AmpsA | OFR

The Sylvania 69261 XBO 900 W OFR is a 900W 6000K Daylight White xenon short-arc high-pressure lamp delivering 30,000 initial lumens at CRI 98, 45 AmpsA DC operating current, 19V operating voltage, 2,400-hour rated life, and ozone-free (OFR) designation. SFa25-10 (Anode), SFa25-12 (Cathode) anode/cathode base configuration. Carbon arc replacement for large-format cinema projection, high-power searchlights, solar simulation, and large-venue follow spot systems. Item 69261. UPC: 46135692611.

Quick Specs

• Brand: Sylvania
• Item / Catalog Number: 69261
• UPC / EAN: 46135692611
• Lamp Type: Xenon Short-Arc High-Pressure (XBO) — Ozone-Free (OFR)
• Wattage: 900W
• Operating Voltage: 19V (DC)
• Operating Current: 45 AmpsA
• Color Temperature: 6000K Daylight White
• CRI: 98
• Initial Lumens: 30,000 lm
• Luminous Intensity: 3000cdcd
• Rated Average Life: 2,400 hours
• Base Type: SFa25-10 (Anode), SFa25-12 (Cathode)
• Overall Length: 325mm
• Burn / Operating Position:
• Gas Fill: Carbon
• Ozone-Free (OFR): Yes — UV-blocking envelope suppresses ozone-generating 185nm radiation

Product Overview

The Sylvania 69261 XBO 900 W OFR is a 900W xenon short-arc high-pressure lamp producing 30,000 lumens at 6000K Daylight White with CRI 98 — a direct current arc source that delivers a compact, extremely bright, daylight-balanced point source appropriate for medium-format cinema, scientific instruments, and compact high-intensity searchlights. At 45 AmpsA operating current and 19V DC, this lamp requires a dedicated constant-current DC power supply rated for these parameters.

The OFR (Ozone-Free) designation indicates this lamp uses a UV-blocking quartz envelope that suppresses the 185nm radiation responsible for ozone generation — appropriate for enclosed or limited-ventilation installations where ozone accumulation must be controlled. The SFa25-10 (Anode), SFa25-12 (Cathode) base provides separate anode and cathode connections; correct DC polarity is essential for lamp operation and safety. Rated life of 2,400 hours varies with operating duty cycle and power supply quality — maintain adequate lamp stock for your production schedule. Burn position: .

Applications

• Large-format cinema projection – XBO xenon short-arc lamps are the professional standard for commercial cinema projection systems requiring maximum screen luminance. 900W output is appropriate for medium-format cinema, scientific instruments, and compact high-intensity searchlights.
• High-power searchlights and follow spots – Large-venue follow spots, aerial searchlights, and entertainment lighting requiring maximum luminous intensity (30,000 lm / 3000cdcd) at extended distances.
• Solar simulation and scientific testing – Solar simulators, UV exposure systems, and optical testing equipment requiring stable CRI 98 daylight-spectrum output at defined wattage.
• ⚠ High-pressure safety warning — face shield mandatory: XBO lamps operate at extreme internal pressure. Always wear a face shield and heavy protective gloves during all handling and installation operations. Lamp burst risk if improperly handled or dropped.

Handling and Installation Requirements

• ⚠ High-pressure — face shield and gloves mandatory: XBO lamps operate at extreme internal pressure. Face shield and heavy protective gloves are required during all handling and installation. Never handle without PPE.
• DC power supply required — 19V DC / 45 AmpsA: XBO lamps require a dedicated constant-current DC power supply. Do not connect to AC. Verify power supply is rated for 19V DC at 45 AmpsA continuous output.
• Anode/cathode polarity — SFa25-10 (Anode), SFa25-12 (Cathode): Verify correct DC polarity per power supply and fixture documentation. Reversed polarity will damage the lamp and may cause failure.
• Burn position — : Operate only within the specified burn position range. Incorrect orientation shortens lamp life and may cause failure.
• Do not touch the lamp envelope: Skin oils cause hot spots that can lead to catastrophic failure under high-pressure operation. Use clean cotton gloves at all times. If touched accidentally, clean with isopropyl alcohol.
• Ozone-free (OFR) — ventilation still required: This lamp suppresses ozone generation, but adequate ventilation is still required due to extreme heat output and UV emissions.
• Allow minimum 30-minute cool-down before handling: XBO lamps operate at extreme temperature. Never touch the housing or lamp immediately after switching off.
• Verify power supply compatibility: Use only power supplies specifically designed and approved for 900W XBO xenon short-arc lamp operation.

Ordering Information

• Brand: Sylvania
• Item / Catalog Number: 69261
• UPC / EAN: 46135692611
• Wattage / DC Voltage: 900W / 19V DC
• Base: SFa25-10 (Anode), SFa25-12 (Cathode)
• Case quantities and bulk pricing: Contact ADL Supply for volume orders.

Safety and Compliance

• ⚠ High-pressure lamp — explosion risk if mishandled. Follow all manufacturer safety guidelines. Protective equipment mandatory during handling.
• Verify RoHS compliance with manufacturer specification sheet.
• Verify applicable FDA radiation performance compliance for your application.
• Verify Prop 65 warning requirements with manufacturer specification sheet.

ADL Supply recommends confirming all specifications with the manufacturer product data sheet prior to specification or installation.
