Sylvania 58720 (ESS) SUPER-Q Halogen Lamp — 250W | 120V Line Voltage | 5,000 Lumens | BA15d Double Contact Bayonet Base

The Sylvania SUPER-Q® Professional 58720 (ESS) Lamp is a commercial-grade, high-intensity line-voltage tungsten halogen capsule engineered exclusively for theatrical stage border lights, television studio fresnels, architectural profile spots, specialized medical diagnostic instruments, and commercial display optical systems. Delivering 5,000 initial lumens of bright 2950K warm white illumination, this premium single-ended bulb features an industry-standard ANSI ESS specification tracking profile and utilizes a precision-aligned CC-8 coiled-coil filament array to achieve a flawless color rendering index of 100 CRI. Outfitted with a heavy-duty, vibration-resistant BA15d double contact bayonet base and a clear high-transmission T4 quartz glass envelope, it ensures perfect optical focal positioning across its 2,000-hour rated average service life.

ADL Supply Expert Application & Replacement Guide

The Sylvania ESS 58720 high-output halogen capsule represents the performance standard for high-wattage thermal delivery within the compact T4 single-ended family. Specially engineered for the intense, demanding environments of theater stages, television studio overhead rigs, professional photography setups, and high-ceiling commercial architectural wash systems, this lamp projects an exceptionally dense full-spectrum point light beam. Utilizing an advanced, vertically braced CC-8 coiled-coil tungsten filament array, it delivers outstanding beam uniformity and a stable color temperature curve without experiencing the sudden color rendering drops or frequency gaps common in alternative solid-state replacements.

Critical 120V Line Voltage Parameters and Mechanical BA15d Bayonet Seating Controls: Licensed electricians and venue maintenance crews executing routine layout upgrades must monitor electrical system boundaries closely prior to checking out: this capsule runs natively on unballasted 120V line voltage tracks and locks into a heavy-duty BA15d double contact bayonet socket. Driving 250 watts of power inside a slim 0.5-inch footprint pushes current lines to a continuous draw of 2.08 Amperes, generating extreme localized thermal profiles across the base prongs.

Installers must push and twist the bayonet base firmly into the socket collar until the dual indexing pins click fully home and seat into their structural tracks. Any loose thread seating, surface carbon pitting, or spring tension loss across the dual lead-solder bottom contacts will introduce heavy contact resistance. This resistance prompts intensive localized arcing feedback loops that will transcend the base's maximum safe **350°C maximum safe thermal limit**, causing catastrophic tracking failures that melt the terminal contacts or weld the bulb base to the fixture socket assembly.

Detailed Product Specifications

• Brand Name: Sylvania (OSRAM Sylvania Display/Optic Specialty Lighting Division)
• Product Series Line: SUPER-Q® Line-Voltage Single-Ended Specialty Halogen Family
• Sylvania Factory Product Order Code SKU: 58720
• Official Industry ANSI Equipment Code: ESS
• Manufacturer Description Model Nomenclature: 250QCL/DC/ESS 120V
• UPC Barcode Number (GTIN-12): 046135587207
• Global Trade Logistics Code (GTIN-13): 00046135587207
• Core Technology Class: Thermal Incandescent — High-Temperature Tungsten Halogen Capsule
• Primary Control Requirement: Direct Unballasted Line Voltage (120V Mainline Branch Input)
• Operational Power Draw: 250 Watts
• Nominal System Operating Voltage: 120 Volts AC/DC Line Voltage Baseline
• Continuous Operating Amperage Draw: 2.08 Amperes continuous line current load
• Initial Luminous Brightness: 5,000 Lumens (Post standard factory seasoning burn)
• Systemic Luminous Efficacy Ratio: 20.0 LPW (Lumens per Watt)
• Color Temperature Configuration: 2950K Warm White (Clear Transparent Optical High-Purity Casing)
• Color Rendering Index (CRI): 100 Ra (Flawless Continuous Full-Spectrum Energy Distribution)
• Filament Type Geometry Class: CC-8 (Precision Calibrated Rigid Coiled-Coil Tungsten Filament)
• Base Type Configuration: BA15d (Double Contact Bayonet Base / 15mm固定 Twist-Lock Interface)
• Maximum Base Shell Temperature Limit: 350°C (662°F Maximum Safe Surface Threshold)
• Maximum Bulb Wall Operating Temperature: 900°C (1652°F Outer Chamber Heat Limit)
• Bulb Shape Enclosure Code: T4 Enclosure Shape (0.50" Inch / 12.7mm actual outer quartz glass casing width)
• Maximum Overall Length (MOL): 3.00" Inches (76.2mm actual structural body height face-to-tip)
• Light Center Length (LCL Dimension): 1.375" Inches (34.93mm precision focal height axis center)
• Dimmable Status: Yes (Fully dimmable down line circuit tracks)
• Chassis Burn Position Limit: Universal — Operates reliably at any horizontal, vertical, or tilted mounting angle
• Fixture Safety Rating: Suitably Enclosed Halogen Luminaires Only Mandatory (Strict fragmentation containment control)
• Manufacturing Craftsmanship Location: Certified Precision Manufacturing Track Made in Germany / USA

Commercial Stage Equipment Industry Cross-References

This standard 250W 120V BA15d halogen bulb serves as a direct drop-in replacement or alternative for the following lines:

• GE Lighting Match: GE Quartzline® 43697 Q250CL/DC-120 Entertainment Lamp
• Philips Lighting Match: Philips 250W 120V T4 Clear BA15d Single-Ended Series
• Ushio Alternative Match: Ushio Q250CL/DC (120V) Specialty Line / Factory Order Code Reference
• Global Entertainment Cross Line: Direct replacement globe for various portable stage lights, specialized projectors, and studio fresnels
