Product Overview
The GE Proline® GEC226-MVPS-3W (Order Code 63097) Ballast is a commercial-grade, multi-voltage electronic control gear module engineered to operate one or two compact fluorescent lamps across an exceptionally broad load matrix. Designed with advanced Programmed Rapid Start (PRS) technology and an auto-sensing universal input network, this single-SKU maintenance solution handles quad-tube GX24q, square 4-pin GR10q, linear plug-in 2G11 PL-L, and circular T5 fluorescent profiles. Outfitted with color-coded terminal blocks and automated end-of-life (EOL) auto-reset circuits, it delivers a high power factor system exceeding 0.98 for modern commercial property sweeps.
|
Lamp Load
1 or 2
Multi-Type CFL
|
Input Voltage
120–277V
108–305V Buffer
|
Start Type
Prog. Start
Requires Un-Shunted
|
Power Factor
>0.98
Active Correction
|
EOL Protection
Auto-Reset
Class A Sound
|
ADL Supply Expert Application & Replacement Guide
The GE GEC226-MVPS-3W is a multi-application commercial control gear baseline specified universally by electrical contractors, real estate engineering teams, and corporate facility branches. By consolidating operations for multiple high-runner lamp profiles—including four-pin quad downlights, square bulkheads, and linear plug-in loops—into a single physical SKU, it eliminates the expensive requirement to inventory dozens of niche, manufacturer-specific ballast types across broad multi-tenant commercial layouts.
Critical Un-Shunted Lamp-holder Mandate & Independent Circuit Architecture: Field technicians executing facility-wide fluorescent upgrades must pay strict attention to socket configurations prior to installation: this Programmed Rapid Start (PRS) ballast requires un-shunted lamp-holders at all terminal connection spots. Un-shunted sockets keep the electrical pin paths isolated, enabling the internal circuitry to safely pass a dedicated preheating current through the tube cathodes before striking the primary arc column. Attempting to run this ballast on shunted sockets (which tie contacts together internally into a single channel) will directly bridge the preheat lines, inducing localized coil overheating, rapid ignition drops, or total destruction of the control board.
The integrated End-of-Life (EOL) Auto-Reset circuit acts as a major operational asset for 24-hour medical centers, airports, and high-security offices. When a lamp fails and the ballast initiates its protective shutdown, maintenance crews can drop in a fresh tube without needing to cycle the main circuit breaker panel. The ballast automatically monitors electrode impedance values and snaps the system back into full ignition fields upon detecting the clean insertion of a new lamp capsule.
|
Verify Before Installing
Un-Shunted Sockets Mandatory — Universal 120-277V Power Grid — No Mercury Content
Please examine the back of your existing fixture lampholders. If retrofitting from older Instant Start devices, old shunted sockets must be replaced with un-shunted variants prior to circuit termination. Always map your lamp count limits via our load matrix rows below—several specialty lamp profiles support single-lamp configurations only.
Mercury and Waste Compliance Notice: This product is a solid-state electronic control ballast and contains 0.0 mg of mercury. It is completely exempt from regional fluorescent shipping regulations and can be legally shipped to all 50 states. Standard commercial electronic waste (e-waste) handling guidelines apply at end-of-life cycles. |
Detailed Product Specifications
- Brand: GE Lighting (Current Lighting Solutions / Proline® Control Gear Line)
- Product Series Line: Proline Multi-Voltage Electronic Compact Fluorescent Series
- GE Factory Product Order Code SKU: 63097
- Manufacturer Description Model: GEC226-MVPS-3W
- UPC Barcode Number (GTIN-12): 043168630979
- Core Technology Class: Solid-State High-Frequency Electronic Ballast
- Starting Method Classification: Programmed Rapid Start (PRS / Sensor-Optimized)
- Lamp Wiring Selection Architecture: Parallel Circuit Operation (Lamps run independently)
- Nominal Operational Input Voltage: 120V to 277V (Direct Line Multi-Volt Auto-Sensing)
- Continuous Input Voltage Security Range: 108V Minimum to 305V Maximum Branch Line Tolerances
- Line Current Frequency Threshold: 50 / 60 Hz
- Systemic Ballast Factor (BF): 0.95 Normal Ballast Factor Performance Scale
- Total Harmonic Distortion (THD) Limit: Less than 10% (Commercial Grade Electrical Isolation)
- Power Factor Correction Level: Active Correction Network (Greater than 0.98)
- Audible Component Sound Rating: Class A (Whisper Quiet Architectural Standard)
- Minimum Operating Ambient Temperature: 0°F (-18°C)
- Enclosure Body Shell Finish: High-Reflectance Anti-Shadow White Enclosure
- Termination Style: Color-Coded Mechanical Terminal Insert Tracks
Certified System Load Matrix (Lamping Matrix)
This multi-lamp controller is fully certified to strike and manage the following tube configurations safely. Do not mix lamp shapes or differing wattages on the same ballast terminal line:
- (1 or 2 Lamps) CFQ26W/G24q: 26-Watt Quad-Tube CFL with GX24q 4-pin bases
- (1 or 2 Lamps) CFTR26W/GX24q: 26-Watt Triple-Tube CFL with GX24q 4-pin bases
- (1 or 2 Lamps) CFS21W/GR10q: 21-Watt Square 2D CFL with GR10q 4-pin bases
- (1 or 2 Lamps) FT24W/2G11: 24-Watt PL-L Twin-Tube CFL with 2G11 linear bases
- (1 Lamp Only) FT36W/2G11: 36-Watt PL-L Twin-Tube CFL with 2G11 linear bases
- (1 Lamp Only) CFTR32W/GX24q: 32-Watt Triple-Tube CFL with GX24q 4-pin bases
- (1 Lamp Only) CFTR42W/GX24q: 42-Watt Triple-Tube CFL with GX24q 4-pin bases
- (1 Lamp Only) CFS28W/GR10q: 28-Watt Square 2D CFL with GR10q 4-pin bases
- (1 Lamp Only) CFS38W/GR10q: 38-Watt Square 2D CFL with GR10q 4-pin bases
- (1 Lamp Only) FC9T5 (22W) or FC12T5 (40W): T5 High-Output Circular Circline lamps
Operation, Safety & Mounting Compliance
High-Frequency Electronic Signal Transformation
This electronic controller cover assembly converts raw municipal alternating current into high-frequency ballast outputs exceeding 40 kHz, completely eliminating stroboscopic facility room eye fatigue and structural flickering loops. It incorporates an automated active surge insulation barrier that blocks standard utility switching transients and operational spikes from breaking down sensitive internal solid-state board capacitors.
Chassis Physical Structural Footprint Dimensions
- Maximum Case Profile Length: 4.94" Inches (125.5mm actual shell length)
- Chassis Housing Section Width: 2.44" Inches (62.0mm actual casing width)
- Chassis Total Housing Height: 0.98" Inches (24.9mm actual vertical thickness)
- Center Mounting Hole Distance: 4.53" Inches (115.1mm center-to-center spacing)
Commercial Control Gear Equipment Cross-References
This universal 63097 ballast serves as a premium drop-in replacement or electrical equivalent for the following models:
- Universal Triad Alternative: C2642UNVME-000K / Order Code 23829 (Direct legacy predecessor line)
- Philips Advance Match: ICN-2S26-N / Centium Multi-Volt Universal Programmed Start
- Sylvania Quicktronic Cross: QHE 2x26-42/UNV PSN / High-Efficiency Programmed CFL Ballast Kit
