HALCO 25421 TruBlu Wireless PIR Occupancy Sensor | Audio Jack | 0-10V | PSC-JBV-I-11N-BLE-SR

PSC-JBV-I-11N-BLE-SR is a TruBlu™ Mesh wireless PIR occupancy sensor-controller designed for indoor fixture integration. This 1-channel controller combines passive infrared occupancy sensing, an integral photosensor, Bluetooth® Mesh wireless control, and 0–10V dimming in a compact 3.5mm audio jack mounted design for panels, troffers, and other indoor luminaires.

Product Overview

This Halco TruBlu™ Mesh wireless PIR occupancy sensor is built for buyers who need compact indoor fixture-level sensing and dimming control for panels, troffers, and similar luminaires. It provides PIR motion detection, integrated daylight harvesting capability, Bluetooth Mesh commissioning, and one 0–10V dimming channel for driver control.

• 1-channel PIR sensor and controller for indoor fixture integration.
• Bluetooth® NLC certified for multi-vendor interoperability.
• Integrated photosensor for ambient light sensing and daylight harvesting.
• Designed for mounting heights up to 15 ft (4.6 m).
• Detection range up to 6 ft (1.8 m) radius.
• Supports daylight harvesting, high-end trim, zoning, continuous dimming, and ON/OFF control.
• Compact design with 3.5mm audio jack mounting for easier integration into compatible fixtures.

Technical Specifications

• Brand: Halco
• Series: Wireless PIR Occupancy Sensor – with Audio Jack
• Model: PSC-JBV-I-11N-BLE-SR
• Product Code: 25421
• SKU: HAL25421
• Product Type: Wireless PIR Occupancy Sensor-Controller
• Sensor Type: Passive Infrared (PIR) with integral photosensor
• Channel: 1-channel
• Input Voltage: 12VDC
• Current Consumption: 30 mA
• Dimming Output: 0–10VDC
• Mounting: 3.5mm Audio Jack
• Maximum Mounting Height: 15 ft (4.6 m)
• Detection Range: Up to 6 ft (1.8 m) radius
• Bluetooth Range: Up to 100 ft (30.4 m)
• Operating Temperature: -20°C to 40°C
• Storage Temperature: -20°C to 50°C
• Relative Humidity: 90–95% non-condensing
• Finish: White
• Environment: Indoor rated
• Certification: Bluetooth® NLC Certified
• Control Platform: Configurable via TruBlu™ web portal or iOS mobile app
• Approx. Dimensions: 2-9/16 in overall length with approx. 3-1/2 in diameter trim face

Operation / Configuration

• Bluetooth® NLC certified device providing true multi-vendor interoperability.
• Configured via TruBlu™ web portal or iOS mobile app.
• Mobile app supports initial commissioning and ongoing parameter adjustments.
• Energy monitoring and demand response are available with TruBlu™ Gateway ordered separately.
• Provides one 0–10V dimming channel for driver control.
• Integrated photosensor enables ambient light sensing and daylight harvesting functions.

Before You Order

• Verify this is the correct indoor PIR occupancy sensor-controller, not a standalone fixture controller.
• Confirm your fixture supports 3.5mm audio jack mounting.
• Requires 12VDC input power.
• Verify your driver supports 0–10V dimming.
• Confirm the mounting height and coverage pattern are suitable for your application.
• Bluetooth range depends on fixture integration, surrounding environment, and installation conditions.
• This model is indoor rated.

Additional Information

This controller is designed for TruBlu™ Mesh networked lighting systems using Bluetooth® Mesh technology. Its compact indoor-rated design, PIR motion sensing, and integrated photosensor make it suitable for fixture-integrated control in panel, troffer, and similar indoor lighting applications.
