GE 23734 FDN-Q500T3/4 – 500W/120V Quartzline Halogen SSTV Lamp | ANSI FDN | 12,800 Lumens | R7s Base | 3200K | Frosted T3

12,800 lumens at 3200K with CRI 100 – a 500W/120V Quartzline halogen lamp with R7s recessed single contact base, frosted T3 bulb, and 400-hour rated life for stage, studio, and theater lighting.

Quick Specs

• Brand: GE (General Electric)
• SKU / Order Code: GELB23734
• Manufacturer Part #: 23734
• ANSI Code: FDN
• Lamp Type: Quartzline Halogen (SSTV)
• Wattage: 500W
• Voltage: 120V
• Base Type: R7s (Recessed Single Contact)
• Bulb Type: T3
• Bulb Finish: Frosted
• Color Temperature: 3200K (Studio White)
• CRI: 100
• Initial Lumens: 12,800 lm
• Rated Average Life: 400 hours
• Filament Type: C8
• Maximum Overall Length (MOL): 4.7 in (119 mm)
• Bulb Diameter: 0.4 in (10 mm)
• Burn Position: Horizontal only (within 4° of level)
• UPC: 043168237345

Product Overview

The GE 23734 FDN Quartzline Halogen Lamp is a 500-watt, 120-volt SSTV lamp delivering 12,800 initial lumens at 3200K with CRI 100. It features an R7s recessed single contact base and a frosted T3 bulb, making it suitable for stage, studio, and theater fixtures that require a linear, double-ended halogen source with warm studio-white color temperature and excellent color rendering.

The C8 filament and compact T3 envelope (4.7-inch MOL, 0.4-inch diameter) fit standard linear halogen fixtures, including certain striplights, floodlights, and accent luminaires. With a 400-hour rated life, this lamp balances output and longevity for professional entertainment applications. Burn position is strictly horizontal (within 4° of level) – verify fixture orientation before ordering.

Why Choose This Product

• 12,800 lumens – high output for 500W linear halogen: Excellent brightness for floodlights, striplights, and accent fixtures in stage and studio environments.
• ANSI FDN – industry-standard replacement: The FDN code guarantees consistent electrical and photometric performance for compatible fixtures.
• 3200K studio white – broadcast-matched color: Camera systems set to 3200K tungsten white balance reproduce colors accurately under this lamp.
• CRI 100 – perfect color rendering: Full-spectrum halogen light ensures accurate color reproduction for film, video, and live events.
• R7s recessed single contact base: Standard for linear halogen lamps, providing secure, spring-loaded contact in compatible fixtures.
• Frosted T3 bulb: Diffuses light output, reducing harsh shadows and providing more even illumination.

Technical Specifications

Dimensions

Applications

• Stage and theater – striplights, border lights, cyclorama floods
• Studio and entertainment – accent lighting, backdrop illumination
• Architectural and display lighting – cove lights, showcase fixtures
• SSTV (Stage, Studio & Theater) luminaires requiring R7s linear halogen lamps

Compatibility & Replacement

Fixture type: This ANSI FDN lamp fits professional stage and studio fixtures designed for an R7s recessed single contact base and 500W/120V linear halogen lamps. Common in striplights, border lights, cyclorama floods, and certain accent fixtures.

Base: R7s – a recessed single contact base with spring-loaded ends, standard for linear halogen lamps. Measure your existing lamp's length to confirm compatibility (this lamp has 4.7-inch MOL).

Ballast: No ballast required – operates directly on 120V mains power.

Before ordering, confirm:

• ANSI code – FDN: Verify your fixture specifies ANSI FDN or equivalent 500W/120V R7s linear halogen lamp.
• Voltage – 120V: Verify fixture and supply circuit are 120V.
• Base type – R7s: Confirm your fixture uses R7s recessed single contact lampholders (spring-loaded ends).
• Burn position – horizontal only: This lamp must be operated horizontally within 4° of level. Do not use in vertical or tilted fixtures.
• Physical dimensions: Verify your fixture accepts a T3 bulb with 4.7-inch overall length and 0.4-inch diameter.
• Fixture wattage rating: Ensure fixture is rated for at least 500W.

Ordering Information

• Brand: GE (General Electric)
• Manufacturer Part #: 23734
• SKU / Order Code: GELB23734
• ANSI Code: FDN
• UPC: 043168237345
• Lamp Type: 500W/120V Quartzline Halogen – R7s Base, Frosted T3, 3200K, 12,800 lm, 400 hr life
• Case quantities and bulk pricing available – contact ADL Supply for volume orders.

Compliance & Certifications

• Verify UL / ETL listing status with manufacturer specification sheet.
• Verify RoHS compliance status with manufacturer specification sheet.
• Verify FDA radiation performance compliance with manufacturer specification sheet.
• Verify Prop 65 warning requirements with manufacturer specification sheet.

ADL Supply recommends confirming all applicable compliance data with the GE official product data sheet (ANSI FDN / Part # 23734) prior to specification or installation.

Safety & Handling Notes

• High pressure warning – face shield required: Quartzline lamps operate under high internal pressure. Always wear a face shield and protective gloves during handling and installation. Lamp burst can cause serious injury.
• No bare hands: Never touch the quartz envelope with bare skin. Oils cause hot spots leading to premature failure or lamp burst. Use clean gloves or a lint-free cloth.
• Do not exceed rated voltage: Operating above 120V dramatically shortens lamp life. Verify supply voltage before installing.
• Burn position – horizontal only (within 4° of level): This lamp is rated for horizontal operation only. Incorrect orientation (vertical or tilted) can cause premature failure or lamp burst.
• Extreme heat and UV output: Use only in approved enclosed luminaires with appropriate UV filtering.
• Allow complete cool-down before handling: Allow lamp to cool completely before relamping. Do not touch immediately after switching off.
• Follow your fixture manufacturer's service documentation for lamp replacement procedures.
