Sylvania 67507 LU100/D/MED

Product Overview

```html

Sylvania 67507 LU100/D/MED Lumalux — 100W HPS Lamp, 2100K Warm Amber, E26 Medium Base, Diffuse

The Sylvania 67507 LU100/D/MED Lumalux is a 100-watt High Pressure Sodium (HPS) lamp from Sylvania, designed for outdoor area lighting, street lighting, parking lots, and commercial/industrial high-bay applications. With an E26 Medium Screw base, ANSI S54/O, E17 bulb shape, 2100K warm amber color temperature, CRI ~22, 9,000 initial lumens, universal burn position, diffuse coated outer envelope, and a rated life of 24,000 hours, this lamp delivers high-efficiency HPS illumination for long-service outdoor and industrial lighting. Requires a compatible HPS ballast rated for ANSI S54/O. Not interchangeable with Metal Halide or Mercury Vapor ballasts. Verify ANSI code, wattage, and base type before ordering.

Wattage

100W

HPS Lumalux

Lumens

9,000 lm

Initial Output

Color Temp

2100K

CRI ~22

Base

E26

Medium Screw

Rated Life

24,000 hrs

Average Life

Technical Specifications

Brand	Sylvania
Series	Sylvania Lumalux
Sylvania Order Code	67507
Manufacturer Part Number	67507-LU100-D-MED
Lamp Type	High Pressure Sodium (HPS) — Diffuse
Wattage	100W
ANSI Code	S54/O
Initial Lumens	9,000 lm
CRI	~22
Color Temperature	2100K Warm Amber
Base Type	E26 Medium Screw
Bulb Shape	E17
Outer Envelope	Diffuse (D) — coated for reduced glare and uniform light distribution
Burn / Operating Position	Universal
Rated Average Life	24,000 hours
Warm-Up Time	3–5 minutes
Hot Restrike Time	10–20 minutes
Mercury Content	Contains mercury — dispose per local regulations
UPC / EAN	46135675072

Product Overview

The Sylvania 67507 LU100/D/MED Lumalux is a 100W High Pressure Sodium lamp for outdoor area, street, parking lot, and commercial/industrial high-bay lighting. HPS technology delivers extremely high luminous efficacy and exceptionally long rated life (24,000 hours) — making it the traditional standard for high-efficiency area and roadway lighting where energy efficiency and maintenance cost reduction are priorities over color rendering.

The Diffuse (D) variant features a coated outer envelope that softens and diffuses the characteristic HPS warm amber output, reducing glare and hotspot intensity for more comfortable, uniform area illumination compared to clear-envelope HPS lamps. The 2100K warm amber color temperature and CRI ~22 are characteristic of standard HPS technology — not appropriate for applications requiring accurate color rendering. This lamp operates on an HPS ballast rated for ANSI S54/O. It will not operate on Metal Halide or Mercury Vapor ballasts — confirm ballast type before ordering.

Compatible Applications

Outdoor area and street lighting — Roadways, parking lots, municipal streetlights, and perimeter security lighting requiring high-efficiency, long-life HPS sources.
Industrial and commercial high-bay — Warehouses, manufacturing facilities, and large indoor/outdoor commercial fixtures using E26 base HPS lamps.
Retrofit and maintenance replacement — Direct replacement for existing 100W HPS lamps with E26 base and ANSI S54 designation.

Before Ordering — Verify

ANSI Code: Confirm the existing ballast is rated for S54/O (100W HPS). This lamp will not operate on MH, CMH, or Mercury Vapor ballasts.
Ballast Type: Confirm the ballast is specifically an HPS ballast rated for S54/O. Incorrect ballast type will cause immediate lamp failure.
Wattage: Confirm fixture and ballast are rated for 100W.
Base Type: Confirm socket matches E26 Medium Screw.
Variant: This is the Diffuse (D) version — if a clear envelope is required, order the clear variant.
Outer Envelope Integrity: Do not operate if the outer envelope is broken or cracked — the inner arc tube emits UV radiation without the protective outer envelope.

Safety and Handling Guidelines

HPS Ballast Only: Use only with a compatible HPS ballast rated for ANSI S54/O. Do not use on MH, CMH, or Mercury Vapor ballasts.
Allow Warm-Up Time: Allow 3–5 minutes for the lamp to reach full output after starting.
Hot Restrike: After switching off, allow 10–20 minutes before restarting.
UV Radiation: Do not operate if the outer envelope is broken or cracked. Use only in fixtures with UV-protective shielding.
Mercury Content: Contains mercury. Do not dispose of in regular trash. Recycle through an approved lamp recycling program. Visit lamprecycle.org for local options.

Compliance

Contains mercury — subject to applicable lamp recycling and disposal regulations. California, Washington, and other states may have mandatory take-back or handling fee requirements.
Verify RoHS and Prop 65 compliance with the Sylvania manufacturer specification sheet prior to use in regulated installations.
