Product Overview

Sylvania 67515 LU100/D – 100W | 2100K Warm Amber | CRI ~22 | ANSI S54/O | Diffuse (D) | E39 Mogul Screw

The Sylvania 67515 LU100/D is a 100W 2100K Warm Amber High Pressure Sodium (HPS) lamp in the Sylvania Lumalux series, ANSI S54/O, E39 Mogul Screw, 9,000 initial lumens, 24,000 hours rated life, Diffuse (D) variant, ET23.5 bulb. Requires a compatible HPS ballast — do not use on MH or mercury vapor ballasts. Contains mercury — dispose per local regulations. UPC: 46135675157. MPN: 67515-LU100-D.

Wattage

100W

HPS Lumalux

Color Temp

2100K

CRI ~22

ANSI Code

S54/O

Ballast Code

Rated Life

24,000

Hours

Base

E39

Mogul

Quick Specs

Brand: Sylvania
Series: Sylvania Lumalux
Sylvania Order Code: 67515
Manufacturer Part Number: 67515-LU100-D
UPC: 46135675157
ANSI Code: S54/O
Lamp Type: High Pressure Sodium (HPS) — Lumalux
Wattage: 100W
Operating Voltage: Universal
Color Temperature: 2100K Warm Amber
CRI: ~22
Initial Lumens: 9,000 lm
Rated Average Life: 24,000 hours
Base Type: E39 Mogul Screw
Bulb Shape: ET23.5
Burn / Operating Position: Universal
Variant: Diffuse (D)
Mercury Content: Contains mercury — dispose per local regulations.

Product Overview

The Sylvania 67515 LU100/D is a 100W 2100K Warm Amber Sylvania Lumalux High Pressure Sodium lamp. Diffuse (D) lamps feature a coated outer envelope that softens and diffuses the arc tube light, reducing glare and hotspots for more uniform, comfortable area illumination.

HPS ballast required. Operate on a compatible HPS ballast matched to ANSI S54/O. Not interchangeable with metal halide or mercury vapor ballasts. Contains mercury — dispose per local regulations.

Applications

Outdoor area and street lighting – Roadways, parking lots, municipal streetlights, and perimeter security lighting.
Industrial and commercial high-bay – Warehouses, manufacturing facilities, and large indoor/outdoor commercial fixtures.
Retrofit and maintenance replacement – Verify ANSI code, wattage, and base type before ordering. HPS lamps require an HPS-rated ballast.

Safety and Installation

HPS ballast required. Operate only on a High Pressure Sodium ballast rated for ANSI S54/O. Do not use on MH or mercury vapor ballasts.
Allow warm-up time: 3–5 minutes for full output.
Hot restrike: Allow 10–20 minutes after switching off before restarting.
UV radiation: Use only in fixtures with UV-protective shielding. Do not operate with a broken or cracked outer envelope.
Mercury disposal: Contains mercury — dispose per local lamp recycling regulations.
