Product Overview
Philips Advance E-Vision IMH150HLF Is A 150 Watt ANSI Code M102/M142/E IntelliVolt 120-277V With Minimum Starting Temp. -30°C/-20°F & Side exit leads with mounting feet 1.0 Ballast Factor Metallic enclosure Ballast Which provide Higher efficiency, Greater lumen maintenance, Longer lamp life,Enhanced color control
- Rated Wattage 150W
- Catalog No.IMH-150-H-LF
- Max Distance To Lamp 5ft.
- Ballasts are sound rated A
- Resettable thermal protection
- Minimum Starting Temp. -20ºC/-4ºF
- 90°C maximum case temperature
- Dim: 6.3in (L) x 3.6in (W) x 1.5in (H)
- Maximum Harmonic Distortion of 15%.
- Superior heat transfer relative to plastic
- Enhancing safety and durability
- Meets universal code compliance
- Rated Voltage: Intellivolt 120V Or 277V (50/60hz)
- Reduction of lamp overpowering and/or thermal stress
- by shutting down should the lamp
- EOL detection removes power from lamps when they
- behave erratically Or fail to ignite
- Feature high power factor (>0.9, a ballast factor of 1.0)
- Reach end-of-life, enhancing safety and preventing lamp cycling
- LF-Ballast with side exit leads and mounting feet, Leads exit
INSTALLATION & APPLICATION NOTES:
1. Maximum allowable case temperature is 90°C.
2. Ignition pulse is 4 kV max
3. All leads are 9 inches long
4. Ballast output will shutdown after 20 minutes if lamp fails to ignite
5. Power must be cycled off – then on, after replacing lamp
6. Connect the red lead to the center terminals of the lamp when using screw base lamps
